SNAP-TITEH Series Hydraulic Quick-Connect Coupling Bodies

SNAP-TITE Hydraulic Quick Connect Hose Coupling: 1 in, Steel, 132.49 lpm Max. Flow Rate

The SNAP-TITE H Series Hydraulic Quick-Connect Coupling Body (MPN VHC16-16FV) is a steel, female NPTF coupling with a 1"-11-1/2 thread size and a maximum flow rate of 132.49 lpm. It features a fluorocarbon seal…

SKU 3G-OTH-462720

Brand

SNAP-TITE

Item

Hydraulic Quick Connect Hose Coupling: 1 in, Steel, 132.49 lpm Max. Flow Rate

Technical Specifications

SNAP-TITE

Manufacturer Part Number

VHC16-16FV

Type

Steel, 132.49 lpm Max. Flow Rate, Female NPTF

Thread Size

1"-11-1/2

Seal Material

Fluorocarbon

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SNAP-TITE Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the SNAP-TITE VHC16-16FV hydraulic quick connect coupling used for?

The SNAP-TITE VHC16-16FV is a steel hydraulic quick-connect coupling body used to rapidly connect and disconnect hydraulic lines in industrial systems. It is designed for applications requiring a 1" female NPTF thread and a maximum flow rate of 132.49 lpm, with a fluorocarbon seal for fluid compatibility.

What are the specifications of the SNAP-TITE VHC16-16FV coupling?

The SNAP-TITE VHC16-16FV is a steel hydraulic quick-connect coupling body with a 1"-11-1/2 female NPTF thread, a maximum flow rate of 132.49 lpm, and a fluorocarbon seal material. It is part of the H Series and is designed for reliable hydraulic connections in industrial systems.

Where to buy the SNAP-TITE VHC16-16FV coupling worldwide?

3G Electric supplies the SNAP-TITE VHC16-16FV hydraulic quick-connect coupling body to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this steel, 1" female NPTF coupling.

How to select the right SNAP-TITE hydraulic quick connect coupling?

To select the correct SNAP-TITE coupling, match the thread size (e.g., 1"-11-1/2 female NPTF), maximum flow rate (132.49 lpm), and seal material (fluorocarbon) to your system's pressure and fluid type. Ensure the coupling body is compatible with your hose ends and operating environment for leak-free connections.

Used in

Common applications for SNAP-TITE

Hydraulic tool maintenance — SNAP-TITE IH Series couplings (e.g., VIHC6-6F) for quick hose connections in hydraulic wrenches and crimpers.

Agricultural equipment — SNAP-TITE IH Series couplings (e.g., VIHC4-4M) for hydraulic lines on tractors and harvesters.

Construction machinery — SNAP-TITE IH Series couplings (e.g., VIHC8-8F) for hydraulic circuits on excavators and loaders.

Industrial fluid power systems — SNAP-TITE IH Series couplings (e.g., VIHC12-12F) for connecting hydraulic power units to actuators.

Mobile hydraulic systems — SNAP-TITE IH Series couplings (e.g., VIHC6-6M) for quick disconnects on forklifts and aerial lifts.
