SOLER & PALAU In-Line Duct Fan: 544 cfm Max., 8 in Duct, 180 W, 120V AC, 1 Ph, IP44 - General Purpose Inline Duct Fans
SOLER & PALAUGeneral Purpose Inline Duct Fans

SOLER & PALAU In-Line Duct Fan: 544 cfm Max., 8 in Duct, 180 W, 120V AC, 1 Ph, IP44

The SOLER & PALAU PV-200X is a general-purpose in-line duct fan with a maximum airflow of 544 cfm, designed for 8-inch ducts. It operates on 120V AC single-phase power with a single speed, includes a mounting…

SKU 3G-OTH-79243

Brand
SOLER & PALAU
Item
In-Line Duct Fan: 544 cfm Max., 8 in Duct, 180 W, 120V AC, 1 Ph, IP44
Category
General Purpose Inline Duct Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SOLER & PALAU
Manufacturer Part Number
PV-200X
Type
180 W, IP44, Galvanized Steel
AC
120V
Ph
1
Duct
8 in
Includes
Mounting Bracket
Number of Speeds
1
Nameplate Voltage
120V AC
Speed Controllable
Yes
High-Efficiency Motor
No
High-Efficiency Motor Broad
Standard-Efficiency Motor
Airflow @ 0.000 in SP - Range
500 to 749 cfm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SOLER & PALAU Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SOLER & PALAU PV-200X is a general-purpose in-line duct fan with a maximum airflow of 544 cfm, designed for 8-inch ducts. It operates on 120V AC single-phase power with a single speed, includes a mounting bracket, and features a standard-efficiency motor. The fan is speed-controllable and has an IP44 rating, with a galvanized steel construction.

Frequently Asked Questions

What is the SOLER & PALAU PV-200X in-line duct fan used for?

The SOLER & PALAU PV-200X is a general-purpose in-line duct fan used for moving air in HVAC systems, ventilation, and exhaust applications. It handles up to 544 cfm through 8-inch ducts, making it suitable for commercial or industrial spaces requiring reliable airflow with speed control.

What are the specifications of the SOLER & PALAU PV-200X?

The SOLER & PALAU PV-200X has a maximum airflow of 544 cfm, fits 8-inch ducts, and operates on 120V AC single-phase power at 180 W. It features a single-speed, standard-efficiency motor, is speed-controllable, has an IP44 rating, and is made of galvanized steel. Includes a mounting bracket.

Where to buy the SOLER & PALAU PV-200X worldwide?

3G Electric supplies the SOLER & PALAU PV-200X in-line duct fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this model.

How to install the SOLER & PALAU PV-200X in-line duct fan?

Install the SOLER & PALAU PV-200X by securing the included mounting bracket to a rigid surface, then attaching the fan to the bracket. Connect 8-inch ductwork to both inlet and outlet, ensuring airtight seals. Wire the 120V AC single-phase supply per local codes, and verify speed control compatibility before powering on.
