SOURIAU Electrical Connector: Trim Trio UTSX 14, Square Flange Receptacle, 7 Contacts - Trim Trio UTSX Harsh Environment Circular Connectors
SOURIAUTrim Trio UTSX Harsh Environment Circular Connectors

SOURIAU Electrical Connector: Trim Trio UTSX 14, Square Flange Receptacle, 7 Contacts

The SOURIAU Trim Trio UTSX 14 is a harsh environment circular connector from the Trim Trio UTSX series, designed as a square flange receptacle with 7 female PCB contacts. It features a 1/3 bayonet coupling, an IP68…

SKU 3G-OTH-09645

Brand
SOURIAU
Item
Electrical Connector: Trim Trio UTSX 14, Square Flange Receptacle, 7 Contacts
Category
Trim Trio UTSX Harsh Environment Circular Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SOURIAU
Manufacturer Part Number
UTSX014D7S
Series
Trim Trio UTSX
Type
Square Flange Receptacle, 12 A, 600V
Contacts
7
IP Rating
IP68
Wire Size
0.318 in to 0.405 in Socket Contact
Contact Type
PCB
Coupling Type
1/3 Bayonet
Contact Gender
Female
Voltage Rating
600V
Connector Design
Square Flange Receptacle
Connector Number
UTSX14D7
Includes Contacts
Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SOURIAU Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SOURIAU Trim Trio UTSX 14 is a harsh environment circular connector from the Trim Trio UTSX series, designed as a square flange receptacle with 7 female PCB contacts. It features a 1/3 bayonet coupling, an IP68 rating, a voltage rating of 600V, and accepts wire sizes from 0.318 in to 0.405 in socket contacts. Contacts are included with the connector.

Frequently Asked Questions

What is the SOURIAU Trim Trio UTSX 14 connector used for?

The SOURIAU Trim Trio UTSX 14 is a harsh environment circular connector used in industrial automation, marine, and outdoor equipment. Its IP68 rating and 1/3 bayonet coupling make it suitable for applications requiring reliable sealing against dust and water immersion.

What are the specifications of the SOURIAU UTSX014D7S connector?

The SOURIAU UTSX014D7S is a square flange receptacle with 7 female PCB contacts, rated at 600V and 12A. It accepts wire sizes from 0.318 in to 0.405 in socket contacts, features a 1/3 bayonet coupling, and has an IP68 rating. Contacts are included.

Where to buy SOURIAU Trim Trio UTSX connectors worldwide?

3G Electric supplies SOURIAU Trim Trio UTSX connectors worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on the UTSX014D7S or other SOURIAU models.

How to install the SOURIAU Trim Trio UTSX square flange receptacle?

Mount the square flange receptacle using the four corner holes onto a panel. Insert the female PCB contacts into the connector body per the wire size range (0.318 in to 0.405 in). Engage the 1/3 bayonet coupling by aligning and twisting until locked. Ensure the IP68 seal is intact.

Used in

Common applications for SOURIAU
Industrial automation — SOURIAU Trim Trio UTGX connectors for sensor and actuator cabling in washdown zones
Railway signaling — SOURIAU UTSX square flange receptacles for PCB-mounted connections in control cabinets
Marine deck equipment — SOURIAU UTGX plugs with IP69K rating for high-pressure hose-down environments
Renewable energy inverters — SOURIAU Trim Trio contacts (RC series) for power and signal wiring in junction boxes
Off-road vehicle lighting — SOURIAU Trim Trio circular connectors for ruggedized lamp harnesses
