SPEEDAIRE Single Rear Clevis: Flange Mount Type, Fits 20 mm Bore Dia, Aluminum
The SPEEDAIRE Single Rear Clevis (SKU 5TJT6) is a flange-mount clevis mounting hardware component, model NCG-C020. It is constructed of aluminum and is designed as a single clevis bracket for use with 20 mm bore…
SKU 3G-OTH-145654
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE Single Rear Clevis (SKU 5TJT6) is a flange-mount clevis mounting hardware component, model NCG-C020. It is constructed of aluminum and is designed as a single clevis bracket for use with 20 mm bore diameter cylinders.
Frequently Asked Questions
What is the SPEEDAIRE Single Rear Clevis used for?
The SPEEDAIRE Single Rear Clevis is a flange-mount clevis bracket used to attach the rear of a pneumatic cylinder to a machine frame or structure. It accommodates 20 mm bore diameter cylinders and is commonly applied in industrial automation, packaging, and material handling systems.
What are the specifications of the SPEEDAIRE Single Rear Clevis?
The SPEEDAIRE Single Rear Clevis, model NCG-C020, is a single clevis bracket made of aluminum. It features a flange mount type and fits 20 mm bore diameter cylinders. The part is compatible with cylinder series 5THU7 to 5VDA3 and is manufactured under MPN NCG-C020.
Where to buy SPEEDAIRE Single Rear Clevis worldwide?
3G Electric supplies the SPEEDAIRE Single Rear Clevis worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this clevis mounting hardware for your pneumatic cylinder applications.
How to install the SPEEDAIRE Single Rear Clevis?
To install the SPEEDAIRE Single Rear Clevis, first ensure the cylinder bore is 20 mm. Align the clevis bracket with the cylinder rear flange and secure it using appropriate bolts. Verify the clevis pin aligns freely without binding. Follow standard pneumatic mounting practices for proper operation.
