SPEEDAIRE Rear Pivot Bracket: Flange/Foot Mount Type, Fits 50 mm Bore Dia
The SPEEDAIRE Rear Pivot Bracket is a stainless steel mounting bracket designed for flange or foot mounting. It fits a 50 mm bore diameter and is identified by manufacturer part number CG-E050SUS.
SKU 3G-OTH-146893
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE Rear Pivot Bracket is a stainless steel mounting bracket designed for flange or foot mounting. It fits a 50 mm bore diameter and is identified by manufacturer part number CG-E050SUS.
Frequently Asked Questions
What is the SPEEDAIRE Rear Pivot Bracket used for?
The SPEEDAIRE Rear Pivot Bracket is used to mount pneumatic cylinders with a 50 mm bore diameter in flange or foot configurations. It provides a pivot point for the cylinder's rear end, allowing angular movement in automated machinery, packaging lines, and material handling systems.
What are the specifications of the SPEEDAIRE Rear Pivot Bracket?
The SPEEDAIRE Rear Pivot Bracket, model CG-E050SUS, is made of stainless steel and fits a 50 mm bore diameter. It is a mounting bracket designed for flange or foot mounting. The stainless steel construction offers corrosion resistance for demanding industrial environments.
Where to buy the SPEEDAIRE Rear Pivot Bracket worldwide?
You can source the SPEEDAIRE Rear Pivot Bracket CG-E050SUS through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the bracket reaches your facility reliably.
How to install the SPEEDAIRE Rear Pivot Bracket?
To install the SPEEDAIRE Rear Pivot Bracket, first align the bracket with the cylinder's rear mounting holes. Secure it using appropriate bolts and torque to manufacturer specifications. Ensure the pivot pin moves freely before connecting the cylinder to your application.
Used in
Common applications for SPEEDAIRESPEEDAIRE Products
3G Electric supplies SPEEDAIRE pivot mounting brackets. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
