SPEEDAIRE Rod Clevis Kit: Clevis Mount Type, Fits 1 1/4 in_1 1/2 in Bore Dia
The SPEEDAIRE Rod Clevis Kit (SKU 5VKW4) is a clevis mounting hardware component made of steel. It is designed as a piston rod clevis and fits 1 1/4 in to 1 1/2 in bore diameters with an overall length of 1 11/16 in.
SKU 3G-OTH-145597
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE Rod Clevis Kit (SKU 5VKW4) is a clevis mounting hardware component made of steel. It is designed as a piston rod clevis and fits 1 1/4 in to 1 1/2 in bore diameters with an overall length of 1 11/16 in.
Frequently Asked Questions
What is the SPEEDAIRE Rod Clevis Kit used for?
The SPEEDAIRE Rod Clevis Kit is used to attach a pneumatic cylinder's piston rod to a mating machine component, allowing pivoting motion. It is commonly applied in industrial automation, packaging, and material handling systems where a clevis mount is required for rod-end connections.
What are the specifications of the SPEEDAIRE Rod Clevis Kit 5VKW4?
The SPEEDAIRE Rod Clevis Kit (MPN 5VKW4) is a steel piston rod clevis. It fits cylinder bore diameters of 1 1/4 in to 1 1/2 in and has an overall length of 1 11/16 in. The kit includes the clevis and necessary mounting hardware for rod-end attachment.
Where to buy the SPEEDAIRE Rod Clevis Kit worldwide?
You can source the SPEEDAIRE Rod Clevis Kit worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this clevis mounting hardware.
How to install the SPEEDAIRE Rod Clevis Kit?
To install the SPEEDAIRE Rod Clevis Kit, thread the clevis onto the piston rod end and secure it with the provided pin and cotter or retaining ring. Ensure the clevis aligns with the mating bracket to avoid side loading. Torque to manufacturer specifications for the cylinder model.
Used in
Common applications for SPEEDAIRESPEEDAIRE Products
3G Electric supplies SPEEDAIRE clevis mounting hardware. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
