SPEEDAIRE Cylinder Mounting Hardware: Foot Mount Type, Fits 4 in Bore Dia
The SPEEDAIRE 5VNX6 is a foot mount type cylinder mounting bracket made of aluminum. It is designed to fit cylinders with a 4-inch bore diameter and has an overall length of 4 13/16 inches. This foot mounting…
SKU 3G-OTH-143542
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE 5VNX6 is a foot mount type cylinder mounting bracket made of aluminum. It is designed to fit cylinders with a 4-inch bore diameter and has an overall length of 4 13/16 inches. This foot mounting hardware provides a stable base for industrial cylinder installations.
Frequently Asked Questions
What is the SPEEDAIRE 5VNX6 foot mount used for?
The SPEEDAIRE 5VNX6 foot mount is used to secure pneumatic cylinders with a 4-inch bore diameter to machinery or structural frames. It provides a stable, aluminum base that prevents cylinder rotation and absorbs vibration during operation, making it suitable for industrial automation, packaging, and material handling applications.
What are the specifications of the SPEEDAIRE 5VNX6 foot mount?
The SPEEDAIRE 5VNX6 foot mount is made of aluminum and fits cylinders with a 4-inch bore diameter. Its overall length is 4 13/16 inches. The manufacturer part number is 5VNX6. This foot mount type bracket is designed for secure, stable cylinder mounting in industrial equipment.
Where to buy the SPEEDAIRE 5VNX6 foot mount worldwide?
You can source the SPEEDAIRE 5VNX6 foot mount through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SPEEDAIRE mounting hardware for your industrial cylinder installations.
How to install the SPEEDAIRE 5VNX6 foot mount on a cylinder?
To install the SPEEDAIRE 5VNX6 foot mount, first align the bracket's mounting holes with the cylinder's foot-mount pattern. Secure the bracket using appropriate bolts and torque to manufacturer specifications. Ensure the mount sits flat on the machine surface to prevent misalignment. Always follow the cylinder manufacturer's installation guidelines for safe operation.
