SPEEDAIRE Cylinder Mounting Hardware: Clevis Mount Type, Fits 1 1/2 in_2 in Bore Dia
The SPEEDAIRE 5VNY3 is a clevis mounting bracket made of aluminum. This clevis mount type hardware is designed for cylinder mounting applications.
SKU 3G-OTH-145572
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE 5VNY3 is a clevis mounting bracket made of aluminum. This clevis mount type hardware is designed for cylinder mounting applications.
Frequently Asked Questions
What is the SPEEDAIRE 5VNY3 clevis mount used for?
The SPEEDAIRE 5VNY3 clevis mount is used to attach a pneumatic cylinder to a machine frame or structure, allowing pivoting motion. It fits cylinders with 1 1/2 in to 2 in bore diameter and is made of aluminum for lightweight corrosion resistance.
What are the specifications of the SPEEDAIRE 5VNY3 clevis bracket?
The SPEEDAIRE 5VNY3 is a clevis bracket made of aluminum, with manufacturer part number 5VNY3. It is designed as clevis mount type hardware for cylinder mounting, fitting bore diameters of 1 1/2 in to 2 in. The material is aluminum for durability.
Where to buy SPEEDAIRE 5VNY3 clevis mount worldwide?
You can source the SPEEDAIRE 5VNY3 clevis mount through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.
How to install the SPEEDAIRE 5VNY3 clevis mount on a cylinder?
To install the SPEEDAIRE 5VNY3 clevis mount, align the clevis bracket with the cylinder rod end clevis pin holes. Insert the pin and secure with a cotter pin or retaining ring. Ensure the bracket is properly aligned to avoid binding during cylinder operation.
Used in
Common applications for SPEEDAIRESPEEDAIRE Products
3G Electric supplies SPEEDAIRE clevis mounting hardware. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
