SPEEDAIRE Cylinder Mounting Hardware: Clevis, Fits 40 mm Bore Dia, 52 mm Overall Lg
The SPEEDAIRE Clevis Mounting Hardware (SKU 3G-OTH-143230) is a clevis bracket made of aluminum. It fits a 40 mm bore diameter and has a 52 mm overall length. This component is designed for use with compatible…
SKU 3G-OTH-143230
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE Clevis Mounting Hardware (SKU 3G-OTH-143230) is a clevis bracket made of aluminum. It fits a 40 mm bore diameter and has a 52 mm overall length. This component is designed for use with compatible pneumatic cylinders.
Frequently Asked Questions
What is the SPEEDAIRE 3G-OTH-143230 clevis mounting hardware used for?
The SPEEDAIRE 3G-OTH-143230 clevis bracket is used to mount pneumatic cylinders with a 40 mm bore diameter. It provides a pivoting connection point, allowing the cylinder rod to attach to a machine component while accommodating angular misalignment during operation.
What are the specifications of the SPEEDAIRE 3G-OTH-143230 clevis bracket?
The SPEEDAIRE 3G-OTH-143230 is a clevis bracket made of aluminum. It fits cylinders with a 40 mm bore diameter and has an overall length of 52 mm. The manufacturer part number is 3G-OTH-143230. This hardware is designed for use with compatible pneumatic cylinders.
Where to buy SPEEDAIRE 3G-OTH-143230 clevis mounting hardware worldwide?
You can source the SPEEDAIRE 3G-OTH-143230 clevis bracket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.
How to install the SPEEDAIRE 3G-OTH-143230 clevis bracket on a pneumatic cylinder?
To install the SPEEDAIRE 3G-OTH-143230 clevis bracket, first ensure the cylinder bore is 40 mm. Slide the clevis over the cylinder rod end and align the pin holes. Insert the provided pin and secure with a retaining ring or cotter pin. Torque fasteners to manufacturer specifications.
