SQUARE D Magnetic Motor Starter: Non-Reversing, 2 Poles, NEMA Size 0, 18 A - Enclosed Non-Reversing Starters with Thermal Overloads
SQUARE DEnclosed Non-Reversing Starters with Thermal Overloads

SQUARE D Magnetic Motor Starter: Non-Reversing, 2 Poles, NEMA Size 0, 18 A

The SQUARE D Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, NEMA Size 0, 2 poles, 18 A, and a 220/240V AC coil (MPN 8536SBG1V03). It is a single-phase unit with screw clamp…

SKU 3G-OTH-40469

Brand
SQUARE D
Item
Magnetic Motor Starter: Non-Reversing, 2 Poles, NEMA Size 0, 18 A
Category
Enclosed Non-Reversing Starters with Thermal Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SBG1V03
Type
NEMA Size 0, 18 A
Phase
Single
Poles
2
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
1 Melting Alloy Unit (Not Included)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, NEMA Size 0, 2 poles, 18 A, and a 220/240V AC coil (MPN 8536SBG1V03). It is a single-phase unit with screw clamp terminals, no operator controls, no pilot light, and no auxiliary contacts. One melting alloy thermal unit (not included) is required for overload protection.

Frequently Asked Questions

What is the SQUARE D 8536SBG1V03 magnetic motor starter used for?

The SQUARE D 8536SBG1V03 is an enclosed non-reversing magnetic motor starter used to start and stop single-phase motors in industrial applications such as conveyors, pumps, and fans. It provides overload protection via a melting alloy thermal unit (not included) and is rated for 18 A at 240V AC.

What are the specifications of the SQUARE D 8536SBG1V03 starter?

The SQUARE D 8536SBG1V03 is a NEMA Size 0, non-reversing, 2-pole starter with a 220/240V AC coil. It has screw clamp terminals, no operator controls, no pilot light, and no auxiliary contacts. It requires one melting alloy thermal unit (not included) for overload protection and is rated for 18 A single-phase operation.

Where to buy the SQUARE D 8536SBG1V03 starter worldwide?

You can source the SQUARE D 8536SBG1V03 magnetic motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to select the correct thermal unit for the SQUARE D 8536SBG1V03 starter?

To select the correct melting alloy thermal unit for the SQUARE D 8536SBG1V03 starter, match the unit's trip rating to the full-load current of your motor. Refer to the SQUARE D thermal unit selection chart for the appropriate part number. The starter requires one thermal unit (not included) for overload protection.
