SQUARE D Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Enclosed Non-Reversing Starters with Thermal Overloads
SQUARE DEnclosed Non-Reversing Starters with Thermal Overloads

SQUARE D Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The SQUARE D Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, NEMA Size 1, 3 poles, 27 A, and a 220/240V AC coil. It is a three-phase unit with screw clamp terminals, no operator…

SKU 3G-OTH-40688

Brand
SQUARE D
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Enclosed Non-Reversing Starters with Thermal Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SCG3V03
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
3 Melting Alloy Units (Not Included)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, NEMA Size 1, 3 poles, 27 A, and a 220/240V AC coil. It is a three-phase unit with screw clamp terminals, no operator controls, no pilot light, and no auxiliary contacts. Three melting alloy thermal units are required but not included.

Frequently Asked Questions

What is the SQUARE D 8536SCG3V03 magnetic motor starter used for?

The SQUARE D 8536SCG3V03 is an enclosed non-reversing magnetic motor starter used to start and protect three-phase AC motors in industrial applications such as pumps, fans, and conveyors. It provides overload protection via three melting alloy thermal units (not included) and is rated NEMA Size 1, 27 A, with a 240V AC coil.

What are the specifications of the SQUARE D 8536SCG3V03 starter?

The SQUARE D 8536SCG3V03 is a NEMA Size 1, non-reversing, three-pole magnetic motor starter rated 27 A. It has a 220/240V AC coil voltage, three-phase operation, screw clamp terminals, and no operator controls or pilot light. Three melting alloy thermal units are required but not included. It is an enclosed unit with thermal overloads.

Where to buy the SQUARE D 8536SCG3V03 worldwide?

You can source the SQUARE D 8536SCG3V03 magnetic motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SQUARE D components to industrial buyers internationally.

How to select thermal units for the SQUARE D 8536SCG3V03 starter?

To select thermal units for the SQUARE D 8536SCG3V03, match the melting alloy heater element to the full-load current of your motor. The starter requires three melting alloy thermal units (not included) for overload protection. Refer to the motor nameplate amps and SQUARE D heater selection tables to choose the correct unit size for reliable protection.
