SQUARE D Foot Switch: 9002AW Series, 1 Pedals, Maintained - Single-Pedal Foot Switches
SQUARE DSingle-Pedal Foot Switches

SQUARE D Foot Switch: 9002AW Series, 1 Pedals, Maintained

The SQUARE D 9002AW Series Foot Switch (MPN 9002AW14) is a single-pedal, electrically corded foot switch with a maintained switch action and DPDT configuration. It includes a foot guard and is part of the 9002AW…

SKU 3G-OTH-30827

Brand
SQUARE D
Item
Foot Switch: 9002AW Series, 1 Pedals, Maintained
Category
Single-Pedal Foot Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
9002AW14
Series
9002AW
Power Source
Electrically Corded
Switch Action
Maintained
Foot Guard Included
Guard Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D 9002AW Series Foot Switch (MPN 9002AW14) is a single-pedal, electrically corded foot switch with a maintained switch action and DPDT configuration. It includes a foot guard and is part of the 9002AW series from SQUARE D.

Frequently Asked Questions

What is the SQUARE D 9002AW14 foot switch used for?

The SQUARE D 9002AW14 foot switch is used for hands-free machine control in industrial environments. Its maintained DPDT action keeps circuits engaged until manually reset, making it suitable for continuous operations like conveyor systems, presses, or assembly line equipment.

What are the specifications of the SQUARE D 9002AW14 foot switch?

The SQUARE D 9002AW14 is a single-pedal foot switch from the 9002AW series. It features a maintained switch action, DPDT configuration, and includes a foot guard. It is electrically corded and operates without batteries. The manufacturer part number is 9002AW14.

Where to buy the SQUARE D 9002AW14 foot switch worldwide?

3G Electric supplies the SQUARE D 9002AW14 foot switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this maintained DPDT foot switch.

How to install the SQUARE D 9002AW14 foot switch?

Install the SQUARE D 9002AW14 by mounting it on a stable, dry surface and connecting the corded leads to your control circuit per the wiring diagram. Ensure the foot guard is properly positioned. Always follow local electrical codes and disconnect power before installation.
