SQUARE D Replacement Coil: 24V AC, NEMA Size 0/00/1
The SQUARE D Replacement Coil (MPN 3104140020) is a 24V AC replacement coil designed for NEMA Size 0, 00, and 1 contactors. It is compatible with the 8502 Type SC Starters series. This coil provides the specified…
SKU 3G-OTH-42727
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The SQUARE D Replacement Coil (MPN 3104140020) is a 24V AC replacement coil designed for NEMA Size 0, 00, and 1 contactors. It is compatible with the 8502 Type SC Starters series. This coil provides the specified voltage for actuating the contactor in industrial motor control applications.
Frequently Asked Questions
What is the SQUARE D Replacement Coil 3104140020 used for?
The SQUARE D Replacement Coil 3104140020 is used to actuate NEMA Size 0, 00, and 1 contactors in industrial motor control applications. It is specifically designed for the 8502 Type SC Starters series, providing the 24V AC voltage needed to engage the contactor for starting and stopping motors.
What are the specifications of the SQUARE D Replacement Coil 3104140020?
The SQUARE D Replacement Coil 3104140020 operates at 24V AC and is compatible with NEMA Size 0, 00, and 1 contactors. It is designed for the 8502 Type SC Starters series. The manufacturer part number is 3104140020. This coil provides the specified voltage for reliable contactor actuation in industrial environments.
Where to buy the SQUARE D Replacement Coil 3104140020 worldwide?
You can source the SQUARE D Replacement Coil 3104140020 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SQUARE D components for motor control applications.
How to select the correct replacement coil for a SQUARE D contactor?
To select the correct replacement coil, match the coil voltage (e.g., 24V AC) and NEMA size (0, 00, or 1) to your existing contactor. Verify compatibility with the contactor series, such as the 8502 Type SC Starters. Always consult the manufacturer's documentation or a qualified technician to ensure proper fit and safe operation.
