SQUARE D Miniature Circuit Breaker: 110 A, 277/480V AC, Single Phase, 18kA at 277/480V AC - EDB & EGB Series, Bolt-On Square D Miniature Circuit Breakers
SQUARE DEDB & EGB Series, Bolt-On Square D Miniature Circuit Breakers

SQUARE D Miniature Circuit Breaker: 110 A, 277/480V AC, Single Phase, 18kA at 277/480V AC

The SQUARE D EDB24110 is a 110 A, single-phase miniature circuit breaker from the EDB & EGB Series, designed for bolt-on installation. It has an AC voltage rating of 277/480V AC and a maximum AIR rating of 18kA at…

SKU 3G-OTH-22538

Brand
SQUARE D
Item
Miniature Circuit Breaker: 110 A, 277/480V AC, Single Phase, 18kA at 277/480V AC
Category
EDB & EGB Series, Bolt-On Square D Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
EDB24110
Type
Single Phase, 18kA at 277/480V AC
AC
277/480V
Amps
110 A
Phase
Single
Poles
2
For Use With
Square D NF Panelboards
Max. AIR Rating
18kA at 277/480V AC
AC Voltage Rating
277/480V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D EDB24110 is a 110 A, single-phase miniature circuit breaker from the EDB & EGB Series, designed for bolt-on installation. It has an AC voltage rating of 277/480V AC and a maximum AIR rating of 18kA at 277/480V AC. This 2-pole breaker is intended for use with Square D NF Panelboards.

Frequently Asked Questions

What is the SQUARE D EDB24110 miniature circuit breaker used for?

The SQUARE D EDB24110 is a 110 A, single-phase miniature circuit breaker designed for bolt-on installation in Square D NF Panelboards. It protects electrical circuits from overloads and short circuits in commercial and industrial applications, with a maximum AIR rating of 18kA at 277/480V AC.

What are the specifications of the SQUARE D EDB24110?

The SQUARE D EDB24110 is a 2-pole, single-phase miniature circuit breaker rated at 110 A and 277/480V AC. It has a maximum AIR rating of 18kA at 277/480V AC and is part of the EDB & EGB Series. It is designed for bolt-on use with Square D NF Panelboards.

Where to buy the SQUARE D EDB24110 worldwide?

3G Electric supplies the SQUARE D EDB24110 miniature circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us to order this Square D breaker for your panelboard application.

How to install the SQUARE D EDB24110 circuit breaker?

The SQUARE D EDB24110 is a bolt-on miniature circuit breaker designed for Square D NF Panelboards. Ensure the panel is de-energized before installation. Align the breaker with the bus bar, tighten the bolt to the manufacturer's torque specification, and verify secure connection. Always follow local electrical codes.
