SQUARE D NEMA Control Relay: Surface Relay Mounting, 120V AC Coil Volt
The SQUARE D NEMA Control Relay is a surface-mounted relay with 8 normally open contacts rated at 10 A and a 120V AC coil. This 8501XO80V02 model provides straightforward switching control for industrial electrical…
SKU 3G-OTH-35841
Need installation or engineering help?
Ask a question
Product Description
The SQUARE D NEMA Control Relay is a surface-mounted relay with 8 normally open contacts rated at 10 A and a 120V AC coil. This 8501XO80V02 model provides straightforward switching control for industrial electrical systems.
Frequently Asked Questions
What is the SQUARE D 8501XO80V02 control relay used for?
The SQUARE D 8501XO80V02 is a NEMA control relay used for switching industrial loads in motor control, conveyor systems, and automation panels. Its 8 normally open contacts and 10 A rating suit high-cycle applications requiring reliable signal isolation and load switching in harsh environments.
What are the specifications of the SQUARE D 8501XO80V02 relay?
This SQUARE D NEMA control relay has a 120V AC coil voltage, 8 normally open contacts rated at 10 A, and a surface relay mounting style. The manufacturer part number is 8501XO80V02. It is designed for industrial control panels and heavy-duty switching applications.
Where to buy the SQUARE D 8501XO80V02 relay worldwide?
3G Electric supplies the SQUARE D 8501XO80V02 relay worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this relay to any international destination.
How to install a SQUARE D surface-mount control relay?
Mount the SQUARE D 8501XO80V02 relay on a flat surface using the provided slots. Wire the 120V AC coil to the control circuit and connect load wires to the normally open contacts rated at 10 A. Follow NEC guidelines and verify coil voltage matches your supply before energizing.
Used in
Common applications for SQUARE DSQUARE D Products
3G Electric supplies SQUARE D surface-mounted relays. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
