SQUARE D Definite Purpose Magnetic Contactor: 2 Poles, 24V AC, 30 A - Non-Reversing Definite Purpose Contactors
SQUARE DNon-Reversing Definite Purpose Contactors

SQUARE D Definite Purpose Magnetic Contactor: 2 Poles, 24V AC, 30 A

The SQUARE D 8910 Series Type DPA Non-Reversing Definite Purpose Contactor is a single-phase, 2-pole HVACR definite purpose contactor with a 24V AC coil and a 2NO main pole contact form. It features a maximum voltage…

SKU 3G-OTH-41751

Brand
SQUARE D
Item
Definite Purpose Magnetic Contactor: 2 Poles, 24V AC, 30 A
Category
Non-Reversing Definite Purpose Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8910DPA32V14
Series
8910 Series Type DPA
Type
30 A, Non-Reversing
AC
24V
Phase
Single
Coil Voltage
24V AC
Contactor Style
HVACR Definite Purpose Contactor
Main Pole Contact Form
2NO
Maximum Voltage Rating
600V AC
Terminal Connection Type
Quick-Disconnect Terminals
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D 8910 Series Type DPA Non-Reversing Definite Purpose Contactor is a single-phase, 2-pole HVACR definite purpose contactor with a 24V AC coil and a 2NO main pole contact form. It features a maximum voltage rating of 600V AC and quick-disconnect terminals.

Frequently Asked Questions

What is the SQUARE D 8910DPA32V14 definite purpose contactor used for?

The SQUARE D 8910DPA32V14 is a definite purpose contactor designed for HVACR applications such as air conditioning, refrigeration, and heat pump systems. It switches single-phase loads up to 30 A with a 24V AC coil, making it suitable for compressor and fan motor control in commercial and industrial equipment.

What are the specifications of the SQUARE D 8910DPA32V14 contactor?

The SQUARE D 8910DPA32V14 is a 2-pole, non-reversing definite purpose contactor with a 24V AC coil, 30 A rating, and 2NO main pole contact form. It has a maximum voltage rating of 600V AC, quick-disconnect terminals, and is part of the 8910 Series Type DPA for single-phase HVACR systems.

Where to buy the SQUARE D 8910DPA32V14 contactor worldwide?

You can source the SQUARE D 8910DPA32V14 contactor through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this SQUARE D definite purpose contactor.

How to install the SQUARE D 8910DPA32V14 definite purpose contactor?

To install the SQUARE D 8910DPA32V14, ensure power is off and the coil voltage matches your 24V AC control circuit. Connect line and load wires to the quick-disconnect terminals, and secure the contactor on a DIN rail or panel. Follow NEC and local codes; consult the SQUARE D manual for torque specs.
