STARRETT Back Plunger Dial Indicator: 0 in to 0.2 in, Inch, Mechanical
The STARRETT Back Plunger Dial Indicator (MPN 196B1) is a mechanical, continuous-reading back-plunger dial indicator with a 0 in to 0.2 in range and a 0-100 dial reading. This inch-graduated instrument is designed…
SKU 3G-OTH-222648
Need installation or engineering help?
Ask a question
Product Description
The STARRETT Back Plunger Dial Indicator (MPN 196B1) is a mechanical, continuous-reading back-plunger dial indicator with a 0 in to 0.2 in range and a 0-100 dial reading. This inch-graduated instrument is designed for precise measurement tasks in industrial settings.
Frequently Asked Questions
What is the STARRETT Back Plunger Dial Indicator used for?
The STARRETT Back Plunger Dial Indicator (MPN 196B1) is used for precise comparative measurements in industrial machining, quality inspection, and toolroom setups. Its 0 in to 0.2 in range and 0-100 dial reading allow operators to detect minute variations in part dimensions, runout, or surface flatness during manufacturing processes.
What are the specifications of the STARRETT 196B1 dial indicator?
The STARRETT 196B1 is a mechanical, continuous-reading back-plunger dial indicator with an inch-graduated range of 0 in to 0.2 in and a 0-100 dial reading. It features a back-plunger design for versatile mounting in fixtures or stands, and is manufactured by STARRETT for reliable shop-floor measurement.
Where to buy the STARRETT 196B1 dial indicator worldwide?
3G Electric supplies the STARRETT 196B1 back-plunger dial indicator worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time; we source and deliver this precision instrument to any country.
How to install a STARRETT back-plunger dial indicator?
Mount the STARRETT 196B1 using its back-plunger stem into a suitable indicator stand or magnetic base. Ensure the plunger contacts the workpiece perpendicularly with light preload. Zero the 0-100 dial by rotating the bezel. For best results, follow general shop practices for dial indicator setup and avoid over-travel beyond the 0.2 in range.
