STEINEL Nozzle: 1 3/16 in Overall Lg, 1/2 in Overall Wd, 2 5/8 in Overall Ht, Welder - Heat Gun Nozzles
STEINELHeat Gun Nozzles

STEINEL Nozzle: 1 3/16 in Overall Lg, 1/2 in Overall Wd, 2 5/8 in Overall Ht, Welder

The STEINEL Nozzle is a heat gun nozzle designed for use as a welding tip on plastics welders. It fits onto model 09231 and is compatible with STEINEL HG 2510 ESD and TO 1910 E heat guns. The nozzle measures 1 3/16…

SKU 3G-OTH-306995

Brand
STEINEL
Item
Nozzle: 1 3/16 in Overall Lg, 1/2 in Overall Wd, 2 5/8 in Overall Ht, Welder
Category
Heat Gun Nozzles
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

STEINEL
Manufacturer Part Number
Welding Tip (Fits onto 09231)
Type
Welder, Plastics (MPN Welding Tip (Fits onto 09231))
Overall Ht
2 5/8 in
Overall Wd
1/2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

STEINEL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The STEINEL Nozzle is a heat gun nozzle designed for use as a welding tip on plastics welders. It fits onto model 09231 and is compatible with STEINEL HG 2510 ESD and TO 1910 E heat guns. The nozzle measures 1 3/16 in overall length, 1/2 in overall width, and 2 5/8 in overall height.

Frequently Asked Questions

What is the STEINEL Nozzle used for?

The STEINEL Nozzle is a welding tip for plastics welders. It directs hot air from compatible heat guns to fuse plastic materials, making it suitable for repair and fabrication tasks in automotive, construction, and industrial settings.

What are the specifications of the STEINEL Nozzle?

This STEINEL Nozzle measures 1 3/16 in overall length, 1/2 in overall width, and 2 5/8 in overall height. It is a welding tip that fits onto model 09231 and is compatible with STEINEL HG 2510 ESD and TO 1910 E heat guns.

Where to buy the STEINEL Nozzle worldwide?

3G Electric supplies the STEINEL Nozzle worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the STEINEL Nozzle on a heat gun?

To install, ensure the heat gun is cool and unplugged. Align the nozzle's base with the heat gun's outlet and push firmly until it clicks or seats securely. For the STEINEL HG 2510 ESD or TO 1910 E, the nozzle fits onto model 09231. Always follow the manufacturer's safety guidelines.

Used in

Common applications for STEINEL
Plastic welding — STEINEL speed welding tip for HG 2520 E used in joining PVC sheets
Heat shrink tubing — STEINEL reflector tip for HG 2320 ESD applied to electrical insulation
Floor covering installation — STEINEL welding iron tip for HG 2310 LCD used in adhesive activation
Industrial heat sealing — STEINEL 10mm reduction nozzle for HG 2620 E on heat seal connectors
Tubing processing — STEINEL 75mm spreader nozzle for HL 1620 E in heat shrinking operations
PVC reducer applications — STEINEL 9mm reducer tip for HG 2320 ESD in pipe forming
