TELEMECANIQUE SENSORS External Thread Connector: 5 Pin, M12 Male Thread, IP67, Screw Terminals - Field-Wireable Industrial M12 Circular Connectors
TELEMECANIQUE SENSORSField-Wireable Industrial M12 Circular Connectors

TELEMECANIQUE SENSORS External Thread Connector: 5 Pin, M12 Male Thread, IP67, Screw Terminals

The TELEMECANIQUE External Thread Connector: 5 Pin is a field-wireable industrial M12 circular connector from TELEMECANIQUE SENSORS. It features a straight orientation, M12 male thread, screw terminals, and a plastic…

SKU 3G-OTH-11319

Brand
TELEMECANIQUE SENSORS
Item
External Thread Connector: 5 Pin, M12 Male Thread, IP67, Screw Terminals
Category
Field-Wireable Industrial M12 Circular Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TELEMECANIQUE SENSORS
Manufacturer Part Number
XZCC12MDM50B
Type
M12 Male Thread, IP67, Screw Terminals, Straight
IP Rating
IP67
Thread Size
M12
Wiring Type
Screw Terminals
Mounting Style
Male Thread
Voltage Rating
36V DC
Connection Type
Cable Assembly
Housing Material
Plastic
Connector Body Type
Pin
Connector Application
For General Sensor Applications
Connector Orientation
Straight
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TELEMECANIQUE SENSORS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TELEMECANIQUE External Thread Connector: 5 Pin is a field-wireable industrial M12 circular connector from TELEMECANIQUE SENSORS. It features a straight orientation, M12 male thread, screw terminals, and a plastic housing with an IP67 rating. The connector is rated for 36V DC and is designed for general sensor applications.

Frequently Asked Questions

What is the TELEMECANIQUE XZCC12MDM50B connector used for?

The TELEMECANIQUE XZCC12MDM50B is a field-wireable M12 circular connector used for general sensor applications. It provides a reliable 5-pin connection with screw terminals, rated for 36V DC, and is suitable for industrial environments requiring IP67 protection against dust and water.

What are the specifications of the TELEMECANIQUE XZCC12MDM50B connector?

The TELEMECANIQUE XZCC12MDM50B is a 5-pin M12 male thread connector with screw terminals, straight orientation, and a plastic housing. It is rated for 36V DC and IP67. The connector body type is pin, and it is designed for general sensor applications.

Where to buy the TELEMECANIQUE XZCC12MDM50B connector worldwide?

3G Electric supplies the TELEMECANIQUE XZCC12MDM50B connector worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this M12 field-wireable connector to your facility. Contact us for availability and lead time.

How to wire the TELEMECANIQUE XZCC12MDM50B connector?

To wire the TELEMECANIQUE XZCC12MDM50B, strip the cable ends, insert each conductor into the corresponding screw terminal, and tighten the screws securely. Ensure the cable gland is properly sealed to maintain the IP67 rating. Always follow the manufacturer's wiring diagram for correct pin assignment.
