TELEMECANIQUE SENSORS Vacuum Switch: 9016G, DPDT, 100 psi Pressure - Max
The TELEMECANIQUE SENSORS 9016G is a diaphragm vacuum switch for sensitive-control applications, featuring two thresholds and a DPDT contact configuration. It has a maximum pressure rating of 100 psi and a 1/4-18"…
SKU 3G-OTH-32203
Need installation or engineering help?
Ask a question
Product Description
The TELEMECANIQUE SENSORS 9016G is a diaphragm vacuum switch for sensitive-control applications, featuring two thresholds and a DPDT contact configuration. It has a maximum pressure rating of 100 psi and a 1/4-18" FNPT pressure connection type, as specified by manufacturer part number 9016GAW21F.
Frequently Asked Questions
What is a TELEMECANIQUE SENSORS 9016G vacuum switch used for?
The TELEMECANIQUE SENSORS 9016G diaphragm vacuum switch is used for sensitive-control applications that require two thresholds and a DPDT contact configuration. It monitors vacuum or pressure up to 100 psi in industrial pneumatic systems, providing reliable switching for process control and safety circuits.
What are the specifications of the TELEMECANIQUE SENSORS 9016GAW21F?
The TELEMECANIQUE SENSORS 9016GAW21F vacuum switch has a DPDT contact type, a maximum pressure rating of 100 psi, and a 1/4-18" FNPT pressure connection. It features two thresholds and is part of the 9016G series. The manufacturer part number is 9016GAW21F.
Where to buy TELEMECANIQUE SENSORS 9016G vacuum switches worldwide?
3G Electric supplies TELEMECANIQUE SENSORS 9016G vacuum switches worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this DPDT, 100 psi max pressure switch with 1/4-18" FNPT connection.
How to install a TELEMECANIQUE SENSORS 9016G vacuum switch?
Install the TELEMECANIQUE SENSORS 9016G vacuum switch by connecting the 1/4-18" FNPT port to the system piping using compatible sealant. Wire the DPDT contacts according to your control circuit, ensuring the pressure does not exceed 100 psi. Verify both thresholds are set correctly for your application.
Used in
Common applications for TELEMECANIQUE SENSORSTELEMECANIQUE SENSORS Products
3G Electric supplies TELEMECANIQUE SENSORS diaphragm vacuum switches for sensitive-control applications. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
