THK Linear Guide Carriage: For 42 mm Rail Wd, Ball, HRW Wide Rail Guide - THK HRW Series Ball Carriages
THKTHK HRW Series Ball Carriages

THK Linear Guide Carriage: For 42 mm Rail Wd, Ball, HRW Wide Rail Guide

The THK HRW27CA1SSC1 is a ball carriage from the THK HRW Series, designed for use with a 42 mm rail width. This carbon steel carriage features end seals and side seals, and is classified as Size 27 within the HRW…

SKU 3G-OTH-119745

Brand
THK
Item
Linear Guide Carriage: For 42 mm Rail Wd, Ball, HRW Wide Rail Guide
Category
THK HRW Series Ball Carriages
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

THK
Manufacturer Part Number
HRW27CA1SSC1
Type
HRW Wide Rail Guide
Size
27
Features
End Seal and Side Seal
Carriage Ht
24 mm
Roller Material
Carbon Steel
Carriage Material
Carbon Steel
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

THK Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The THK HRW27CA1SSC1 is a ball carriage from the THK HRW Series, designed for use with a 42 mm rail width. This carbon steel carriage features end seals and side seals, and is classified as Size 27 within the HRW Wide Rail Guide type.

Frequently Asked Questions

What is the THK HRW27CA1SSC1 linear guide carriage used for?

The THK HRW27CA1SSC1 is a ball carriage from the HRW Wide Rail Guide series, used in precision linear motion applications such as CNC machines, robotics, and industrial automation. It supports heavy loads with smooth, low-friction movement on a 42 mm rail.

What are the specifications of the THK HRW27CA1SSC1?

The THK HRW27CA1SSC1 is a Size 27 ball carriage with a 24 mm carriage height, designed for a 42 mm rail width. It is made of carbon steel with carbon steel rollers, and includes end seals and side seals for contamination protection.

Where to buy the THK HRW27CA1SSC1 worldwide?

3G Electric supplies the THK HRW27CA1SSC1 linear guide carriage to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive genuine THK components for your precision motion systems.

How to install the THK HRW27CA1SSC1 carriage?

Install the THK HRW27CA1SSC1 by aligning it with the matching 42 mm rail, ensuring the rail surface is clean and lubricated. Secure the carriage using the specified bolts and torque values, and verify smooth movement before operation. Refer to THK's manual for detailed steps.
