THOMAS & BETTS Wiring Duct: 1 1/2 in Nom Wd, 3.5 in Slot Ht, 4 in Nom Ht, 0.2 in Slot Wd - Screw-Mount Slotted Wiring Ducts & Snap-On Covers
THOMAS & BETTSScrew-Mount Slotted Wiring Ducts & Snap-On Covers

THOMAS & BETTS Wiring Duct: 1 1/2 in Nom Wd, 3.5 in Slot Ht, 4 in Nom Ht, 0.2 in Slot Wd

The THOMAS & BETTS TYD15X4NPG6 is a screw-mount slotted wiring duct base with a snap-on cover, made of PVC in gray. It has a 1 1/2 in nominal width, 4 in nominal height, 3.5 in slot height, 0.2 in slot width, and 72…

SKU 3G-OTH-56720

Brand
THOMAS & BETTS
Item
Wiring Duct: 1 1/2 in Nom Wd, 3.5 in Slot Ht, 4 in Nom Ht, 0.2 in Slot Wd
Category
Screw-Mount Slotted Wiring Ducts & Snap-On Covers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

THOMAS & BETTS
Manufacturer Part Number
TYD15X4NPG6
Type
Wiring Duct Base
Lg
72 in
Nom Ht
4 in
Slot Ht
3.5 in
Slot Wd
0.2 in
Wall Type
Narrow Slot
Item [MERCH]
Flush Cover Wiring Duct
Wall Type - Broad
Slotted
Color (Duct, Cover)
Gray
Compatable Cover Style
Snap-On
Mounting Style (Ducts)
Screw Mount
Material (Duct, Divider, Covers)
PVC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

THOMAS & BETTS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The THOMAS & BETTS TYD15X4NPG6 is a screw-mount slotted wiring duct base with a snap-on cover, made of PVC in gray. It has a 1 1/2 in nominal width, 4 in nominal height, 3.5 in slot height, 0.2 in slot width, and 72 in length. This narrow-slot flush cover wiring duct is designed for organizing and routing wires in electrical enclosures.

Frequently Asked Questions

What is the THOMAS & BETTS TYD15X4NPG6 wiring duct used for?

The THOMAS & BETTS TYD15X4NPG6 is a screw-mount slotted wiring duct base used to organize and route wires inside electrical enclosures, control panels, and junction boxes. Its narrow-slot design and snap-on cover allow secure cable management while maintaining easy access for maintenance or modifications in industrial and commercial installations.

What are the specifications of the THOMAS & BETTS TYD15X4NPG6 wiring duct?

The THOMAS & BETTS TYD15X4NPG6 has a 1 1/2 in nominal width, 4 in nominal height, 3.5 in slot height, 0.2 in slot width, and 72 in length. It is made of gray PVC, features a narrow-slot wall type, and uses screw mounting. The compatible cover style is snap-on, and the item is a flush cover wiring duct base.

Where to buy the THOMAS & BETTS TYD15X4NPG6 wiring duct worldwide?

3G Electric supplies the THOMAS & BETTS TYD15X4NPG6 wiring duct to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact our team to place an order or request a quote for this PVC slotted wiring duct.

How to install the THOMAS & BETTS TYD15X4NPG6 wiring duct?

To install the THOMAS & BETTS TYD15X4NPG6, first cut the duct to the required length using a fine-tooth saw. Secure the base to the enclosure panel using screws through the mounting holes. Route wires through the slots, then snap the compatible cover onto the base. Ensure the cover is fully seated for a secure fit.
