THOMAS & BETTS Wiring Duct: 1 in Nom Wd, 1.3 in Slot Ht, 2 in Nom Ht, 0.2 in Slot Wd, PVC - Screw-Mount Slotted Wiring Ducts & Snap-On Covers
THOMAS & BETTSScrew-Mount Slotted Wiring Ducts & Snap-On Covers

THOMAS & BETTS Wiring Duct: 1 in Nom Wd, 1.3 in Slot Ht, 2 in Nom Ht, 0.2 in Slot Wd, PVC

The THOMAS & BETTS TYD1X2NPW6 is a screw-mount slotted wiring duct base with a nominal width of 1 in, nominal height of 2 in, slot height of 1.3 in, slot width of 0.2 in, and length of 72 in. Made of white PVC, it…

SKU 3G-OTH-56636

Brand
THOMAS & BETTS
Item
Wiring Duct: 1 in Nom Wd, 1.3 in Slot Ht, 2 in Nom Ht, 0.2 in Slot Wd, PVC
Category
Screw-Mount Slotted Wiring Ducts & Snap-On Covers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

THOMAS & BETTS
Manufacturer Part Number
TYD1X2NPW6
Type
Wiring Duct Base
Lg
72 in
Nom Ht
2 in
Slot Ht
1.3 in
Slot Wd
0.2 in
Wall Type
Narrow Slot
Item [MERCH]
Flush Cover Wiring Duct
Wall Type - Broad
Slotted
Color (Duct, Cover)
White
Compatable Cover Style
Snap-On
Mounting Style (Ducts)
Screw Mount
Material (Duct, Divider, Covers)
PVC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

THOMAS & BETTS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The THOMAS & BETTS TYD1X2NPW6 is a screw-mount slotted wiring duct base with a nominal width of 1 in, nominal height of 2 in, slot height of 1.3 in, slot width of 0.2 in, and length of 72 in. Made of white PVC, it features a narrow slot wall type and is designed for use with a snap-on cover (sold separately).

Frequently Asked Questions

What is the THOMAS & BETTS TYD1X2NPW6 wiring duct used for?

The THOMAS & BETTS TYD1X2NPW6 is a screw-mount slotted wiring duct base used to route and protect electrical wires in control panels, industrial enclosures, and automation systems. Its narrow slot wall type organizes cables securely, while the white PVC construction provides insulation and durability. A snap-on cover (sold separately) completes the installation.

What are the specifications of the THOMAS & BETTS TYD1X2NPW6 wiring duct?

The THOMAS & BETTS TYD1X2NPW6 wiring duct base has a nominal width of 1 in, nominal height of 2 in, slot height of 1.3 in, slot width of 0.2 in, and length of 72 in. It is made of white PVC, features a narrow slot wall type, and uses screw mounting. The compatible cover style is snap-on.

Where to buy the THOMAS & BETTS TYD1X2NPW6 wiring duct worldwide?

3G Electric supplies the THOMAS & BETTS TYD1X2NPW6 wiring duct to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this item to meet your project needs.

How to install the THOMAS & BETTS TYD1X2NPW6 wiring duct?

To install the THOMAS & BETTS TYD1X2NPW6 wiring duct, first cut the PVC duct to length using a fine-tooth saw. Secure it to the panel or enclosure surface using screws through the mounting holes. Route wires through the narrow slots, then snap on the compatible cover (sold separately) to enclose and protect the wiring.

Used in

Common applications for THOMAS & BETTS
Industrial control panel wiring organization — Thomas & Betts TYD series wiring ducts and snap-on covers for cable management.
Power distribution cable splicing — Thomas & Betts open barrel compression connectors for 350 kcmil copper conductors.
Hazardous location conduit systems — Thomas & Betts liquid-tight fittings for Class III environments in textile mills.
Motor control center connections — Thomas & Betts motor lead disconnects for 4/0 AWG wire in switchgear.
Conduit pull points and access — Thomas & Betts C-type and LR-type outlet bodies for RMC and IMC installations.
Panel building with flush covers — Thomas & Betts slotted wiring ducts with white covers for aesthetic and functional cable routing.
