THOMSON Linear Bearing Ball Carriage: For 35 mm Rail Wd, Ball, 500 Series Ball Carriage - Thomson 500 Series Ball Carriages
THOMSONThomson 500 Series Ball Carriages

THOMSON Linear Bearing Ball Carriage: For 35 mm Rail Wd, Ball, 500 Series Ball Carriage

The THOMSON 500 Series Ball Carriage (MPN 511H35E1) is a linear bearing ball carriage designed for 35 mm rail width. It features steel alloy carriage and roller materials with an approximate 0.03 C preload. This…

SKU 3G-OTH-123120

Brand
THOMSON
Item
Linear Bearing Ball Carriage: For 35 mm Rail Wd, Ball, 500 Series Ball Carriage
Category
Thomson 500 Series Ball Carriages
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

THOMSON
Manufacturer Part Number
511H35E1
Type
500 Series Ball Carriage
Size
35
Features
Appx. 0.03 C Preload
Roller Material
Steel Alloy
Carriage Material
Steel Alloy
Series Ball Carriage
500
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

THOMSON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The THOMSON 500 Series Ball Carriage (MPN 511H35E1) is a linear bearing ball carriage designed for 35 mm rail width. It features steel alloy carriage and roller materials with an approximate 0.03 C preload. This component is suitable for linear motion applications requiring precise carriage positioning.

Frequently Asked Questions

What is the THOMSON 511H35E1 linear bearing ball carriage used for?

The THOMSON 511H35E1 500 Series Ball Carriage is used in linear motion systems that require precise carriage positioning on a 35 mm rail. It is common in industrial automation, packaging machinery, and material handling equipment where smooth, low-friction linear guidance is needed.

What are the specifications of the THOMSON 511H35E1 ball carriage?

The THOMSON 511H35E1 is a 500 Series Ball Carriage for 35 mm rail width. It has steel alloy carriage and roller materials, with an approximate 0.03 C preload. The manufacturer part number is 511H35E1, and it is designed for precise linear motion applications.

Where to buy THOMSON 511H35E1 ball carriage worldwide?

3G Electric supplies the THOMSON 511H35E1 ball carriage to customers worldwide. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this linear bearing component.

How to select the correct THOMSON ball carriage for a 35 mm rail?

To select the correct THOMSON ball carriage for a 35 mm rail, verify the rail width matches 35 mm and choose the 500 Series carriage like the 511H35E1. Consider the required preload (approx. 0.03 C) and load capacity. Always consult the manufacturer's linear motion guidelines for proper sizing and installation.

Used in

Common applications for THOMSON
Industrial automation — Thomson 500 Series ball carriages (511H25C0D) used in linear motion axes for pick-and-place systems.
Packaging machinery — Thomson profile ball rails (521H30AD+1000) guide conveyor or carton-erecting mechanisms.
Material handling — Thomson linear ball bearings (SUPER32OPN) support sliding loads in transfer stations.
Machine tool — Thomson ball nut end blocks (7829547) integrate with ball screws for CNC table positioning.
Medical equipment — Thomson pre-drilled shaft support rails (LSR-10-PD) mount linear guides in diagnostic scanners.
Automated assembly — Thomson double-acting seals (OPNS1000) protect linear bearings in dusty environments.
