TIMKEN Radial Ball Bearing: 6209, 45 mm Bore, Sngl Shield, 85 mm OD - High-Capacity Retaining Ring Ball Bearings
TIMKENHigh-Capacity Retaining Ring Ball Bearings

TIMKEN Radial Ball Bearing: 6209, 45 mm Bore, Sngl Shield, 85 mm OD

The TIMKEN Radial Ball Bearing: 6209 is a metric high-capacity retaining ring ball bearing with a 45 mm bore, 85 mm OD, and 19 mm outer ring width. It features a single shield and is identified by bearing industry…

SKU 3G-OTH-100239

Brand
TIMKEN
Item
Radial Ball Bearing: 6209, 45 mm Bore, Sngl Shield, 85 mm OD
Category
High-Capacity Retaining Ring Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TIMKEN
Manufacturer Part Number
209WDG
Type
Sngl Shield
Bore
45 mm
OD
85 mm
Outer Ring Wd
19 mm
System of Measurement
Metric
Bearing Industry Number
6209
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TIMKEN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TIMKEN Radial Ball Bearing: 6209 is a metric high-capacity retaining ring ball bearing with a 45 mm bore, 85 mm OD, and 19 mm outer ring width. It features a single shield and is identified by bearing industry number 6209 and manufacturer part number 209WDG.

Frequently Asked Questions

What is the TIMKEN 6209 radial ball bearing used for?

The TIMKEN 6209 radial ball bearing is used in industrial machinery, electric motors, pumps, and gearboxes where high radial load capacity and moderate speed are required. Its single shield design protects against contaminants while retaining lubrication, making it suitable for conveyor systems, fans, and agricultural equipment.

What are the specifications of the TIMKEN 6209 bearing?

The TIMKEN 6209 radial ball bearing has a 45 mm bore, 85 mm OD, and 19 mm outer ring width. It is a metric, single-shielded bearing with bearing industry number 6209 and manufacturer part number 209WDG. This high-capacity retaining ring design supports radial loads in compact assemblies.

Where to buy TIMKEN 6209 bearings worldwide?

You can source TIMKEN 6209 bearings worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this TIMKEN radial ball bearing.

How to select the correct TIMKEN 6209 bearing for an application?

To select the correct TIMKEN 6209 bearing, verify the shaft diameter matches the 45 mm bore and housing fits the 85 mm OD. Confirm the 19 mm width and single-shield configuration suit your speed and contamination requirements. Check load ratings in TIMKEN's catalog; for retaining ring applications, ensure proper axial retention in the housing.

Used in

Common applications for TIMKEN
Conveyor systems — TIMKEN RA115RRB spherical insert bearings for idler rollers and pulleys
Agricultural equipment — TIMKEN RCSM1 cartridge bearing units for tillage and harvesting machinery
Material handling — TIMKEN YASM 1-7/16 pillow block bearings for belt conveyors and elevators
Industrial fans — TIMKEN 6319 radial ball bearings for high-speed fan shafts
Pump drives — TIMKEN SCJ 5/8 flange-mount bearings for close-coupled pump applications
Packaging machinery — TIMKEN YCJ 30 SGT flange-mount bearings for indexing and feed mechanisms
