TIMKEN Radial Ball Bearing: 6316, Sngl Shield, 80 mm Bore, 170 mm OD, 39 mm Wd - High-Capacity Radial Ball Bearings
TIMKENHigh-Capacity Radial Ball Bearings

TIMKEN Radial Ball Bearing: 6316, Sngl Shield, 80 mm Bore, 170 mm OD, 39 mm Wd

The TIMKEN 6316 is a metric radial ball bearing with a single shield, featuring an 80 mm bore, 170 mm OD, and 39 mm width. It is constructed with an alloy steel ring and is identified by bearing industry number 6316…

SKU 3G-OTH-99195

Brand
TIMKEN
Item
Radial Ball Bearing: 6316, Sngl Shield, 80 mm Bore, 170 mm OD, 39 mm Wd
Category
High-Capacity Radial Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TIMKEN
Manufacturer Part Number
316WDN
Type
Sngl Shield, Alloy Steel Ring
Bore
80 mm
OD
170 mm
Wd
39 mm
System of Measurement
Metric
Bearing Industry Number
6316
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TIMKEN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TIMKEN 6316 is a metric radial ball bearing with a single shield, featuring an 80 mm bore, 170 mm OD, and 39 mm width. It is constructed with an alloy steel ring and is identified by bearing industry number 6316 and manufacturer part number 316WDN.

Frequently Asked Questions

What is the TIMKEN 6316 radial ball bearing used for?

The TIMKEN 6316 radial ball bearing is used in industrial machinery such as pumps, compressors, gearboxes, and electric motors. Its single-shield design and alloy steel ring suit moderate-speed, high-load applications where contamination protection is needed.

What are the specifications of the TIMKEN 6316 bearing?

The TIMKEN 6316 is a metric radial ball bearing with an 80 mm bore, 170 mm OD, and 39 mm width. It has a single shield, an alloy steel ring, and bearing industry number 6316 (MPN 316WDN). It is designed for high-capacity radial loads.

Where to buy TIMKEN 6316 bearings worldwide?

You can source TIMKEN 6316 bearings worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct TIMKEN radial ball bearing for an application?

To select the correct TIMKEN radial ball bearing, match the bore size (80 mm), OD (170 mm), and width (39 mm) to your shaft and housing. Consider load rating, speed, and shielding. The 6316 single-shield design suits moderate contamination environments.
