TRITAN Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia - Size 50 Bushed-Bore Roller Chain Sprockets
TRITANSize 50 Bushed-Bore Roller Chain Sprockets

TRITAN Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia

The TRITAN Sprocket: For 50 Chain is a Size 50 Bushed-Bore Roller Chain Sprocket, model 50SDS22H, with 22 teeth, a 4.392-inch pitch diameter, and a 4.72-inch outside diameter, constructed from steel. This sprocket…

SKU 3G-OTH-127267

Brand
TRITAN
Item
Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia
Category
Size 50 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
50SDS22H
Type
Steel
Teeth
22
Pitch Dia
4.392 in
Outside Dia
4.72 in
Required Bushing Series
SDS
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN Sprocket: For 50 Chain is a Size 50 Bushed-Bore Roller Chain Sprocket, model 50SDS22H, with 22 teeth, a 4.392-inch pitch diameter, and a 4.72-inch outside diameter, constructed from steel. This sprocket requires an SDS bushing series for installation.

Frequently Asked Questions

What is the TRITAN 50SDS22H sprocket used for?

The TRITAN 50SDS22H sprocket is used in roller chain drive systems to transmit rotary motion between shafts. It is designed for Size 50 chain and is commonly applied in industrial machinery, conveyors, and power transmission equipment where reliable torque transfer is required.

What are the specifications of the TRITAN 50SDS22H sprocket?

The TRITAN 50SDS22H sprocket has 22 teeth, a pitch diameter of 4.392 inches, and an outside diameter of 4.72 inches. It is made of steel and requires an SDS bushing series for installation. The manufacturer part number is 50SDS22H.

Where to buy the TRITAN 50SDS22H sprocket worldwide?

You can source the TRITAN 50SDS22H sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to install the TRITAN 50SDS22H sprocket?

To install the TRITAN 50SDS22H sprocket, first select the correct SDS bushing series. Align the bushing with the sprocket bore, insert the key, and tighten the set screws. Ensure the sprocket is properly aligned with the chain and shaft before securing. Follow standard industrial sprocket installation practices.
