TRITAN 4 Bolt Flange Bearing: Radial Ball, 1 in Bore, Cast Iron, Eccentric Collar - General Purpose Flange-Mount Ball Bearings
TRITANGeneral Purpose Flange-Mount Ball Bearings

TRITAN 4 Bolt Flange Bearing: Radial Ball, 1 in Bore, Cast Iron, Eccentric Collar

The TRITAN 4 Bolt Flange Bearing is a general purpose flange-mount radial ball bearing with a 1 in cylindrical bore, cast iron housing, and eccentric collar. It features a 3/8 in mounting bolt size, NLGI #2…

SKU 3G-OTH-101253

Brand
TRITAN
Item
4 Bolt Flange Bearing: Radial Ball, 1 in Bore, Cast Iron, Eccentric Collar
Category
General Purpose Flange-Mount Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
HCFU205-16
Type
Cast Iron, Eccentric Collar
Bore
1 in
Lg
3 21/32 in
Bore Type
Cylindrical
Lubricant Material
NLGI #2 Equivalent
Mounting Bolt Size
3/8 in
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN 4 Bolt Flange Bearing is a general purpose flange-mount radial ball bearing with a 1 in cylindrical bore, cast iron housing, and eccentric collar. It features a 3/8 in mounting bolt size, NLGI #2 equivalent lubricant, and a 3 21/32 in length (MPN HCFU205-16). This inch-system bearing is designed for industrial equipment requiring a compact, four-bolt flange mounting configuration.

Frequently Asked Questions

What is the TRITAN 4 Bolt Flange Bearing used for?

The TRITAN 4 Bolt Flange Bearing is a general purpose flange-mount radial ball bearing used in industrial equipment that requires a compact, four-bolt mounting configuration. It supports rotating shafts with a 1 in bore, using an eccentric collar for secure shaft locking, and is suitable for conveyors, fans, and material handling systems.

What are the specifications of the TRITAN HCFU205-16 flange bearing?

The TRITAN HCFU205-16 has a 1 in cylindrical bore, cast iron housing, and a 3 21/32 in length. It uses a 3/8 in mounting bolt size, NLGI #2 equivalent lubricant, and an eccentric collar. This inch-system bearing is designed for general purpose flange-mount applications and is manufactured by TRITAN.

Where to buy the TRITAN 4 Bolt Flange Bearing worldwide?

You can source the TRITAN 4 Bolt Flange Bearing through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this TRITAN HCFU205-16 bearing.

How to install a TRITAN eccentric collar flange bearing?

To install a TRITAN eccentric collar flange bearing, first slide the bearing onto the shaft and align the mounting holes. Tighten the bolts to the specified torque. Then rotate the eccentric collar in the direction of shaft rotation to lock it, and secure the collar with the setscrew. Always follow the manufacturer's instructions for proper preload and alignment.

Used in

Common applications for TRITAN
Poultry processing conveyors — TRITAN food-grade radial ball bearings (SS3829 2RS FM222) with double contact seals
Material handling systems — TRITAN spherical insert bearings (SB205-16G) with set screw locking for shaft mounting
High-temperature oven rollers — TRITAN miniature ball bearings (SSRI814 ZZ SRL) rated to 302°F
Self-lubricating pivot joints — TRITAN spherical plain bearings (GE 30TE 2RS) with PTFE sliding surface
Flange-mounted conveyor idlers — TRITAN 4-bolt flange bearings (UCF210-31) in cast iron housings
Chain drive repairs — TRITAN offset links (40-1R OSL) for ANSI #40 roller chains

TRITAN Products

3G Electric supplies TRITAN general purpose flange-mount ball bearings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
