TRITAN Ball Thrust Bearing: D24, 1 15/16 in Bore Dia, 3 7/32 in Outside Dia - Banded Ball Thrust Bearings
TRITANBanded Ball Thrust Bearings

TRITAN Ball Thrust Bearing: D24, 1 15/16 in Bore Dia, 3 7/32 in Outside Dia

The TRITAN D24 is an inch-system banded ball thrust bearing from the D Series, featuring a 1 15/16 in bore diameter, 3 7/32 in outside diameter, and 0.813 in overall width. It is constructed with AISI 52100 ball…

SKU 3G-OTH-110016

Brand
TRITAN
Item
Ball Thrust Bearing: D24, 1 15/16 in Bore Dia, 3 7/32 in Outside Dia
Category
Banded Ball Thrust Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
D24
Bore Dia
1 15/16 in
Overall Wd
0.813 in
Outside Dia
3 7/32 in
Maximum Speed
1,925 RPM Oil
Bearing Series
D Series
Ball Material Grade
AISI 52100
Thrust Bearing Type
Banded Ball Thrust Bearing
System of Measurement
Inch
Bearing Industry Number
D24
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN D24 is an inch-system banded ball thrust bearing from the D Series, featuring a 1 15/16 in bore diameter, 3 7/32 in outside diameter, and 0.813 in overall width. It is constructed with AISI 52100 ball material grade and has a maximum speed of 1,925 RPM in oil. This bearing is identified by the bearing industry number D24.

Frequently Asked Questions

What is the TRITAN D24 banded ball thrust bearing used for?

The TRITAN D24 banded ball thrust bearing handles axial loads in industrial machinery such as gearboxes, pumps, and compressors. Its inch-system dimensions and AISI 52100 steel balls suit moderate-speed applications requiring reliable thrust support.

What are the specifications of the TRITAN D24 bearing?

The TRITAN D24 is an inch-system banded ball thrust bearing with a 1 15/16 in bore, 3 7/32 in outside diameter, and 0.813 in overall width. It uses AISI 52100 ball material and has a maximum speed of 1,925 RPM in oil. It belongs to the D Series.

Where to buy the TRITAN D24 bearing worldwide?

3G Electric supplies the TRITAN D24 bearing worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct TRITAN D24 bearing for an application?

To select the TRITAN D24, verify the shaft size matches the 1 15/16 in bore and the housing accommodates the 3 7/32 in outside diameter. Confirm the axial load and speed do not exceed 1,925 RPM in oil. Consult the D Series catalog for fit and lubrication guidelines.
