TRITAN Bushed Roller Chain Sprocket: For 40 Chain, 28 Teeth, 4.466 in Pitch Dia - Size 40 Bushed-Bore Roller Chain Sprockets
TRITANSize 40 Bushed-Bore Roller Chain Sprockets

TRITAN Bushed Roller Chain Sprocket: For 40 Chain, 28 Teeth, 4.466 in Pitch Dia

The TRITAN Bushed Roller Chain Sprocket (SKU 55VZ32) is a Size 40 bushed-bore roller chain sprocket designed for 40 chain. It features 28 teeth, a 4.466-inch pitch diameter, and a 4.74-inch outside diameter. This…

SKU 3G-OTH-125970

Brand
TRITAN
Item
Bushed Roller Chain Sprocket: For 40 Chain, 28 Teeth, 4.466 in Pitch Dia
Category
Size 40 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
40BTL28H
Teeth
28
Pitch Dia
4.466 in
Outside Dia
4.74 in
Required Bushing Series
1610
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN Bushed Roller Chain Sprocket (SKU 55VZ32) is a Size 40 bushed-bore roller chain sprocket designed for 40 chain. It features 28 teeth, a 4.466-inch pitch diameter, and a 4.74-inch outside diameter. This sprocket requires a 1610 bushing series and is identified by manufacturer part number 40BTL28H.

Frequently Asked Questions

What is a TRITAN Bushed Roller Chain Sprocket used for?

The TRITAN Bushed Roller Chain Sprocket is used in power transmission systems to transfer rotary motion between shafts via roller chain. It is common in conveyors, packaging machinery, and industrial drives where reliable engagement with 40 chain is required.

What are the specifications of the TRITAN 40BTL28H sprocket?

The TRITAN 40BTL28H is a Size 40 bushed-bore sprocket with 28 teeth, a 4.466-inch pitch diameter, and a 4.74-inch outside diameter. It requires a 1610 bushing series and is designed for 40 roller chain.

Where to buy a TRITAN bushed roller chain sprocket worldwide?

3G Electric supplies the TRITAN 40BTL28H bushed roller chain sprocket to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this sprocket.

How to select the correct bushing for a TRITAN 40BTL28H sprocket?

The TRITAN 40BTL28H sprocket requires a 1610 bushing series. Select a bushing with the appropriate bore size for your shaft diameter. Ensure the bushing keyway and setscrew alignment match your application to prevent slippage during operation.
