TRITAN Bushed Roller Chain Sprocket: For 50 Chain, 16 Teeth, 3.204 in Pitch Dia - Size 50 Bushed-Bore Roller Chain Sprockets
TRITANSize 50 Bushed-Bore Roller Chain Sprockets

TRITAN Bushed Roller Chain Sprocket: For 50 Chain, 16 Teeth, 3.204 in Pitch Dia

The TRITAN Bushed Roller Chain Sprocket is a Size 50 bushed-bore roller chain sprocket designed for 50 chain. It features 16 teeth, a 3.204-inch pitch diameter, and a 3.52-inch outside diameter. This sprocket…

SKU 3G-OTH-126826

Brand
TRITAN
Item
Bushed Roller Chain Sprocket: For 50 Chain, 16 Teeth, 3.204 in Pitch Dia
Category
Size 50 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
50BTL16H
Teeth
16
Pitch Dia
3.204 in
Outside Dia
3.52 in
Required Bushing Series
1610
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN Bushed Roller Chain Sprocket is a Size 50 bushed-bore roller chain sprocket designed for 50 chain. It features 16 teeth, a 3.204-inch pitch diameter, and a 3.52-inch outside diameter. This sprocket requires a 1610 bushing series and is identified by manufacturer part number 50BTL16H.

Frequently Asked Questions

What is the TRITAN Bushed Roller Chain Sprocket used for?

The TRITAN Bushed Roller Chain Sprocket is used in power transmission systems to drive roller chain in industrial machinery. It is designed for Size 50 chain and is commonly applied in conveyors, packaging equipment, and agricultural machinery where reliable torque transfer and precise engagement are required.

What are the specifications of the TRITAN 50BTL16H sprocket?

The TRITAN 50BTL16H is a Size 50 bushed-bore roller chain sprocket with 16 teeth, a 3.204-inch pitch diameter, and a 3.52-inch outside diameter. It requires a 1610 bushing series and is designed for 50 chain. The manufacturer part number is 50BTL16H.

Where to buy TRITAN sprockets worldwide?

TRITAN sprockets are available to order through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact 3G Electric for pricing and lead time on the TRITAN 50BTL16H bushed roller chain sprocket.

How to select the correct bushing for a TRITAN sprocket?

To select the correct bushing for a TRITAN sprocket, match the required bushing series specified by the sprocket. For the 50BTL16H model, the required bushing series is 1610. Always verify the shaft diameter and keyway dimensions against the bushing catalog to ensure proper fit and secure mounting.
