TSUBAKI Sprocket: For 40 Chain, 32 Teeth, 5.101 in Pitch Dia, 5.377 in Outside Dia - Size 40 Bushed-Bore Roller Chain Sprockets
TSUBAKISize 40 Bushed-Bore Roller Chain Sprockets

TSUBAKI Sprocket: For 40 Chain, 32 Teeth, 5.101 in Pitch Dia, 5.377 in Outside Dia

The TSUBAKI Sprocket is a Size 40 bushed-bore roller chain sprocket designed for 40 chain. It features 32 teeth, a 5.101-inch pitch diameter, and a 5.377-inch outside diameter, constructed from steel to ANSI…

SKU 3G-OTH-126745

Brand
TSUBAKI
Item
Sprocket: For 40 Chain, 32 Teeth, 5.101 in Pitch Dia, 5.377 in Outside Dia
Category
Size 40 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TSUBAKI
Manufacturer Part Number
40BTL32
Type
Steel, ANSI
Teeth
32
Pitch Dia
5.101 in
Outside Dia
5.377 in
Required Bushing Series
1610
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TSUBAKI Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TSUBAKI Sprocket is a Size 40 bushed-bore roller chain sprocket designed for 40 chain. It features 32 teeth, a 5.101-inch pitch diameter, and a 5.377-inch outside diameter, constructed from steel to ANSI standards. This model (MPN 40BTL32) requires a 1610 bushing series for installation.

Frequently Asked Questions

What is the TSUBAKI 40BTL32 sprocket used for?

The TSUBAKI 40BTL32 sprocket is used in roller chain drive systems to transmit rotary motion between shafts. It is designed for ANSI 40 chain and is commonly applied in industrial machinery, conveyors, and power transmission equipment where reliable torque transfer is required.

What are the specifications of the TSUBAKI 40BTL32 sprocket?

The TSUBAKI 40BTL32 is a Size 40 bushed-bore roller chain sprocket with 32 teeth, a 5.101-inch pitch diameter, and a 5.377-inch outside diameter. It is made of steel to ANSI standards and requires a 1610 bushing series for installation. The manufacturer part number is 40BTL32.

Where to buy the TSUBAKI 40BTL32 sprocket worldwide?

You can source the TSUBAKI 40BTL32 sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this TSUBAKI sprocket.

How to install the TSUBAKI 40BTL32 bushed-bore sprocket?

To install the TSUBAKI 40BTL32 sprocket, first select a 1610 bushing series that matches your shaft diameter. Insert the bushing into the sprocket bore, align the keyway, and tighten the set screws. Ensure proper chain tension and alignment per standard industrial practice for roller chain drives.

Used in

Common applications for TSUBAKI
Material handling conveyors — TSUBAKI C2080H connecting links for heavy-duty chain systems
Packaging machinery — TSUBAKI size 60 roller chains with 60NEPCL connecting links for coated chain applications
Automotive assembly lines — TSUBAKI 80NPSK1CL attachment links for positioning fixtures on single-strand chains
Food processing equipment — TSUBAKI nickel-plated chains and sprockets (e.g., 50BTL48) for washdown environments
General power transmission — TSUBAKI PL1G keyless bushings for shaft mounting without keyways in drive systems
Conveyor drive systems — TSUBAKI 40BTL24 sprockets for size 40 chain in light-to-medium load applications
