TSUBAKI Sprocket: For 50 Chain, 17 Teeth, 3.401 in Pitch Dia, 3.719 in Outside Dia - Size 50 Bushed-Bore Roller Chain Sprockets
TSUBAKISize 50 Bushed-Bore Roller Chain Sprockets

TSUBAKI Sprocket: For 50 Chain, 17 Teeth, 3.401 in Pitch Dia, 3.719 in Outside Dia

The TSUBAKI Sprocket is a Size 50 bushed-bore roller chain sprocket designed for 50 chain. It features 17 teeth, a 3.401-inch pitch diameter, and a 3.719-inch outside diameter, constructed from steel. This sprocket…

SKU 3G-OTH-126962

Brand
TSUBAKI
Item
Sprocket: For 50 Chain, 17 Teeth, 3.401 in Pitch Dia, 3.719 in Outside Dia
Category
Size 50 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TSUBAKI
Manufacturer Part Number
50BTL17
Type
Steel
Teeth
17
Pitch Dia
3.401 in
Outside Dia
3.719 in
Required Bushing Series
1610
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TSUBAKI Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TSUBAKI Sprocket is a Size 50 bushed-bore roller chain sprocket designed for 50 chain. It features 17 teeth, a 3.401-inch pitch diameter, and a 3.719-inch outside diameter, constructed from steel. This sprocket requires a 1610 bushing series and is identified by manufacturer part number 50BTL17.

Frequently Asked Questions

What is the TSUBAKI 50BTL17 sprocket used for?

The TSUBAKI 50BTL17 sprocket is used in roller chain drive systems to transmit rotary motion between shafts. It is designed for Size 50 chain and is commonly applied in industrial machinery, conveyors, and power transmission equipment where reliable torque transfer is required.

What are the specifications of the TSUBAKI 50BTL17 sprocket?

The TSUBAKI 50BTL17 is a steel sprocket with 17 teeth, a 3.401-inch pitch diameter, and a 3.719-inch outside diameter. It requires a 1610 bushing series and is designed for Size 50 roller chain. The manufacturer part number is 50BTL17.

Where to buy the TSUBAKI 50BTL17 sprocket worldwide?

You can source the TSUBAKI 50BTL17 sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct bushing for the TSUBAKI 50BTL17 sprocket?

The TSUBAKI 50BTL17 sprocket requires a 1610 bushing series. To select the correct bushing, match the bushing bore size to your shaft diameter and ensure the bushing keyway aligns with your shaft key. Always consult the manufacturer's bushing selection guide for proper fit and torque ratings.
