U.S. MOTORSC-Face with Rigid Base 3-Phase General Purpose AC Motors

U.S. MOTORS General Purpose Motor: C-Face Mount, Totally Enclosed Fan Cooled, 20 hp

The U.S. MOTORS U20P1DC is a C-Face with Rigid Base 3-Phase General Purpose AC Motor, featuring a TEFC enclosure. It delivers 20 hp at 3,600 RPM and operates on 230/460V AC with a full load current of 46.0/22.9 A.

SKU 3G-OTH-58178

Brand

U.S. MOTORS

Item

General Purpose Motor: C-Face Mount, Totally Enclosed Fan Cooled, 20 hp

Technical Specifications

U.S. MOTORS

Manufacturer Part Number

U20P1DC

Type

Totally Enclosed Fan Cooled, 20 hp

230/460V

Motor Enclosure

TEFC

Nameplate RPM @ 60 Hz

3,600 RPM

Full Load Current @ 60 Hz

46.0/22.9 A

Nameplate Voltage @ 60 Hz

230/460V AC

MOTORS General Purpose Motor

C-Face Mount

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

U.S. MOTORS Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the U.S. MOTORS U20P1DC general purpose motor used for?

The U.S. MOTORS U20P1DC is a 20 hp, 3,600 RPM C-Face with Rigid Base AC motor used in industrial applications such as pumps, fans, compressors, and conveyors. Its TEFC enclosure protects against dust and moisture, making it suitable for harsh environments.

What are the specifications of the U.S. MOTORS U20P1DC motor?

The U.S. MOTORS U20P1DC is a 20 hp, 3,600 RPM, 230/460V AC, 3-phase motor with a TEFC enclosure. Full load current is 46.0 A at 230V and 22.9 A at 460V. It features a C-Face mount with rigid base for direct coupling to driven equipment.

Where to buy the U.S. MOTORS U20P1DC motor worldwide?

3G Electric supplies the U.S. MOTORS U20P1DC motor to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this C-Face TEFC motor.

How to select the right U.S. MOTORS C-Face motor for an application?

To select the right U.S. MOTORS C-Face motor, match horsepower, RPM, voltage, and enclosure to your load requirements. For the U20P1DC, verify 230/460V AC supply, 3,600 RPM speed, and TEFC protection. Ensure the C-Face mounting flange and shaft dimensions align with your pump or gearbox.

Used in

Common applications for U.S. MOTORS

Pumping systems — U.S. MOTORS A40P1CS (40 hp, 460 V, 3,570 RPM) for centrifugal water pumps in industrial facilities.

HVAC fans — U.S. MOTORS A7P4C (7.5 hp, 460 V, 885 RPM) for large air-handling unit fan drives.

Conveyor drives — U.S. MOTORS A25P1CS (25 hp, 460 V, 3,565 RPM) for material-handling belt conveyors.

Compressor applications — U.S. MOTORS A30P3C (30 hp, 460 V, 1,190 RPM) for rotary screw air compressors.

Machine tool spindles — U.S. MOTORS HD3P1H (3 hp, 200 V, 3,535 RPM) for high-speed milling machine spindles.

Elevator traction — U.S. MOTORS elevator motors (specialized line) for hydraulic or traction elevator systems.
