U.S. MOTORS General Purpose Motor: Rigid Base Mount, Totally Enclosed Fan Cooled, 100 hp - Rigid Base 3-Phase General Purpose AC Motors
U.S. MOTORSRigid Base 3-Phase General Purpose AC Motors

U.S. MOTORS General Purpose Motor: Rigid Base Mount, Totally Enclosed Fan Cooled, 100 hp

The U.S. MOTORS Rigid Base 3-Phase General Purpose AC Motor (SKU 263H05, MPN 8P100P3GB) is a 100 hp, TEFC-enclosed motor with a nameplate voltage of 575V AC at 60 Hz. It operates at 1,185 RPM and draws a full load…

SKU 3G-OTH-74206

Brand
U.S. MOTORS
Item
General Purpose Motor: Rigid Base Mount, Totally Enclosed Fan Cooled, 100 hp
Category
Rigid Base 3-Phase General Purpose AC Motors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

U.S. MOTORS
Manufacturer Part Number
8P100P3GB
Type
Totally Enclosed Fan Cooled, 100 hp
AC
575V
Motor Enclosure
TEFC
Nameplate RPM @ 60 Hz
1,185 RPM
Full Load Current @ 60 Hz
99.0 A
Nameplate Voltage @ 60 Hz
575V AC
MOTORS General Purpose Motor
Rigid Base Mount
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

U.S. MOTORS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The U.S. MOTORS Rigid Base 3-Phase General Purpose AC Motor (SKU 263H05, MPN 8P100P3GB) is a 100 hp, TEFC-enclosed motor with a nameplate voltage of 575V AC at 60 Hz. It operates at 1,185 RPM and draws a full load current of 99.0 A at 60 Hz.

Frequently Asked Questions

What is the U.S. MOTORS 8P100P3GB general purpose motor used for?

This U.S. MOTORS 100 hp TEFC motor is designed for industrial applications requiring a rigid base mount, such as pumps, fans, compressors, and conveyors. Its 575V AC, 60 Hz operation suits heavy-duty machinery in manufacturing, water treatment, and HVAC systems.

What are the specifications of the U.S. MOTORS 8P100P3GB motor?

The U.S. MOTORS 8P100P3GB is a 100 hp, TEFC-enclosed, rigid base mount motor. It operates at 1,185 RPM with a nameplate voltage of 575V AC at 60 Hz and draws a full load current of 99.0 A. The motor enclosure is Totally Enclosed Fan Cooled (TEFC).

Where to buy the U.S. MOTORS 8P100P3GB motor worldwide?

3G Electric supplies the U.S. MOTORS 8P100P3GB motor worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install a U.S. MOTORS rigid base mount motor?

Ensure the mounting surface is level and rigid. Align the motor shaft with the driven equipment using a coupling or belt drive. Securely bolt the base to the foundation. Connect the 575V AC, 60 Hz power supply per the wiring diagram. Verify rotation direction before full operation.

Used in

Common applications for U.S. MOTORS
Pumping systems — U.S. MOTORS A40P1CS (40 hp, 460 V, 3,570 RPM) for centrifugal water pumps in industrial facilities.
HVAC fans — U.S. MOTORS A7P4C (7.5 hp, 460 V, 885 RPM) for large air-handling unit fan drives.
Conveyor drives — U.S. MOTORS A25P1CS (25 hp, 460 V, 3,565 RPM) for material-handling belt conveyors.
Compressor applications — U.S. MOTORS A30P3C (30 hp, 460 V, 1,190 RPM) for rotary screw air compressors.
Machine tool spindles — U.S. MOTORS HD3P1H (3 hp, 200 V, 3,535 RPM) for high-speed milling machine spindles.
Elevator traction — U.S. MOTORS elevator motors (specialized line) for hydraulic or traction elevator systems.

U.S. MOTORS Products

3G Electric supplies U.S. MOTORS rigid base 3-phase general purpose ac motors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
