U.S. MOTORS Pool and Spa Pump Motor: 286T Frame Size, Rigid Base, Open Drip Proof, 40 hp - Dry Hydraulic Elevator Motors
U.S. MOTORSDry Hydraulic Elevator Motors

U.S. MOTORS Pool and Spa Pump Motor: 286T Frame Size, Rigid Base, Open Drip Proof, 40 hp

The U.S. MOTORS Dry Hydraulic Elevator Motor (SKU 617V37, MPN DH40S2HF) is a 40 hp, 200V AC, 1,760 RPM open drip proof (ODP) motor with a 286T frame size and rigid base. It draws 110.0 full load amps at 60 Hz. This…

SKU 3G-OTH-55704

Brand
U.S. MOTORS
Item
Pool and Spa Pump Motor: 286T Frame Size, Rigid Base, Open Drip Proof, 40 hp
Category
Dry Hydraulic Elevator Motors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

U.S. MOTORS
Manufacturer Part Number
DH40S2HF
Type
Rigid Base, Open Drip Proof, 40 hp
AC
200V
Frame Size
286T
Motor Enclosure
ODP
Nameplate RPM @ 60 Hz
1,760 RPM
Full Load Amps @ 60 Hz
110.0 A
Nameplate Voltage @ 60 Hz
200V AC
MOTORS Pool And Spa Pump Motor
286T Frame Size
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

U.S. MOTORS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The U.S. MOTORS Dry Hydraulic Elevator Motor (SKU 617V37, MPN DH40S2HF) is a 40 hp, 200V AC, 1,760 RPM open drip proof (ODP) motor with a 286T frame size and rigid base. It draws 110.0 full load amps at 60 Hz. This motor is designed for dry hydraulic elevator applications.

Frequently Asked Questions

What is the U.S. MOTORS DH40S2HF dry hydraulic elevator motor used for?

The U.S. MOTORS DH40S2HF is a 40 hp, 200V AC, 1,760 RPM open drip proof (ODP) motor designed specifically for dry hydraulic elevator applications. It powers the pump unit that drives the hydraulic cylinder, lifting the elevator car. Its rigid base and 286T frame ensure stable mounting in commercial or industrial elevator systems.

What are the specifications of the U.S. MOTORS DH40S2HF motor?

The U.S. MOTORS DH40S2HF is a 40 hp, 200V AC, 1,760 RPM ODP motor with a 286T frame size and rigid base. It draws 110.0 full load amps at 60 Hz. The motor enclosure is open drip proof (ODP), suitable for indoor dry environments. The manufacturer part number is DH40S2HF.

Where to buy the U.S. MOTORS DH40S2HF motor worldwide?

You can source the U.S. MOTORS DH40S2HF dry hydraulic elevator motor through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this U.S. MOTORS motor.

How to install the U.S. MOTORS DH40S2HF dry hydraulic elevator motor?

Install the U.S. MOTORS DH40S2HF motor on a level, rigid base using the 286T frame mounting holes. Ensure the 200V AC power supply matches the nameplate voltage and that the circuit can handle 110.0 full load amps. Align the motor shaft with the pump coupling, and verify rotation direction per the hydraulic system manual. Always follow local electrical codes.
