VNE Butterfly Valve: 1 in Pipe Size, Clamp, 145 psi Max. Pressure (CWP), 304 Stainless Steel - 3-A Certified Stainless Steel Butterfly Valves
VNE3-A Certified Stainless Steel Butterfly Valves

VNE Butterfly Valve: 1 in Pipe Size, Clamp, 145 psi Max. Pressure (CWP), 304 Stainless Steel

The VNE Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 1-inch pipe size, featuring a 304 SS body and disc, a lever handle, and 12 stop positions. It has a maximum pressure rating of 145 psi…

SKU 3G-OTH-453377

Brand
VNE
Item
Butterfly Valve: 1 in Pipe Size, Clamp, 145 psi Max. Pressure
Category
3-A Certified Stainless Steel Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

VNE
Manufacturer Part Number
625-10791
Type
Clamp, Lever
Handle Type
Lever
Body Material
304 SS
Disc Material
304 SS
Stop Positions
12
Stainless Steel
304
Max. Pressure (CWP)
145 psi
Average Surface Roughness (Ra)
20RA ID/32RA OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

VNE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The VNE Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 1-inch pipe size, featuring a 304 SS body and disc, a lever handle, and 12 stop positions. It has a maximum pressure rating of 145 psi (CWP) and an average surface roughness of 20RA ID/32RA OD. This clamp-style valve is designed for industrial applications requiring sanitary standards.

Frequently Asked Questions

What is the VNE Butterfly Valve used for?

The VNE Butterfly Valve is used in sanitary industrial applications requiring 3-A certification, such as food, dairy, beverage, and pharmaceutical processing. Its 304 stainless steel construction and 20RA ID/32RA OD surface finish meet hygiene standards for clean-in-place systems.

What are the specifications of the VNE Butterfly Valve?

The VNE Butterfly Valve has a 1-inch pipe size, clamp connection, 304 SS body and disc, lever handle with 12 stop positions, and a maximum pressure rating of 145 psi (CWP). It features an average surface roughness of 20RA ID/32RA OD and is 3-A certified.

Where to buy the VNE Butterfly Valve worldwide?

You can source the VNE Butterfly Valve through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this 3-A certified valve.

How to install the VNE Butterfly Valve?

Install the VNE Butterfly Valve between two clamp-style pipe ends using a compatible gasket and clamp. Ensure the valve is fully open before tightening the clamp to avoid damaging the seat. Verify the lever handle aligns with the 12 stop positions for precise flow control.

Used in

Common applications for VNE
Dairy processing — VNE EG45BY-6 ball check valves for backflow prevention in pasteurization lines
Beverage bottling — VNE 93C series pneumatically actuated three-way ball valves for product diversion
Pharmaceutical compounding — VNE EG90CC manual two-way ball valves for sterile fluid transfer
Food ingredient handling — VNE 625 series butterfly valves for flow control in CIP systems
Bioprocessing — VNE 45C spring check valves for preventing contamination in fermentation loops
