WALTER Square Turning Insert: SNMG322-MK5

The WALTER Square Turning Insert SNMG322-MK5 is used for general turning, facing, and profiling operations on steel, stainless steel, and cast iron workpieces. Its square shape provides four cutting edges for cost-effective machining in medium to heavy roughing applications.

The WALTER SNMG090308-MK5 is a square indexable turning insert with an inscribed circle of 9.525 mm and thickness of 3.18 mm. It features a chipbreaker geometry (MK5) optimized for medium machining of steel and stainless steel. The insert is part of the SNMG family and is identified by MPN 6356458.

You can source WALTER turning inserts worldwide through 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on the SNMG322-MK5 and SNMG090308-MK5 inserts.

To select the correct WALTER square turning insert, match the insert size (e.g., SNMG322 or SNMG090308) to your tool holder's pocket dimensions and clamping system. Consider the workpiece material and operation: MK5 grade suits medium machining of steel. Always verify the insert's inscribed circle and thickness against your holder's specifications.
