WEATHERHEAD Compression Fitting Elbow: 1/8 in OD x 1/4 in Pipe Size
The WEATHERHEAD Compression Fitting Elbow (MPN 7405X02X04) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/8 in OD tubing with a 1/4 in pipe size connection. It…
SKU 3G-OTH-470105
Need installation or engineering help?
Ask a question
Product Description
The WEATHERHEAD Compression Fitting Elbow (MPN 7405X02X04) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/8 in OD tubing with a 1/4 in pipe size connection. It features a 5/16-24 x 1/4-18 thread size, providing a reliable, leak-resistant joint in hydraulic and pneumatic systems.
Frequently Asked Questions
What is a WEATHERHEAD Ermeto Flareless compression fitting elbow used for?
The WEATHERHEAD Ermeto Flareless compression fitting elbow (MPN 7405X02X04) creates a leak-resistant, bite-type joint in hydraulic and pneumatic systems. It connects 1/8 in OD tubing to a 1/4 in pipe port, ideal for high-pressure fluid power applications where vibration resistance is critical.
What are the specifications of the WEATHERHEAD 7405X02X04 compression fitting?
This WEATHERHEAD Ermeto Flareless elbow has a 5/16-24 x 1/4-18 thread size, fits 1/8 in OD tubing, and connects to a 1/4 in pipe size port. It is a steel, flareless bite-type fitting designed for reliable sealing in hydraulic and pneumatic systems without flaring the tube.
Where to buy WEATHERHEAD compression fittings worldwide?
3G Electric supplies WEATHERHEAD Ermeto Flareless compression fittings like the 7405X02X04 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site, ensuring you receive genuine industrial components for hydraulic and pneumatic systems.
How to install a WEATHERHEAD flareless bite-type compression fitting?
To install a WEATHERHEAD Ermeto Flareless fitting, insert the tube fully into the fitting until it bottoms out, then tighten the nut to the manufacturer's recommended torque. The bite ring grips the tube without flaring, creating a leak-resistant seal. Always follow standard hydraulic fitting installation practices.
Used in
Common applications for WEATHERHEADWEATHERHEAD Products
3G Electric supplies WEATHERHEAD flareless bite-type steel compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
