WEATHERHEAD Compression Tee Fitting: 3/8 in OD x 1/4 in Pipe x 3/8 in OD Size - Flareless Bite-Type Steel Compression Fittings
WEATHERHEADFlareless Bite-Type Steel Compression Fittings

WEATHERHEAD Compression Tee Fitting: 3/8 in OD x 1/4 in Pipe x 3/8 in OD Size

The WEATHERHEAD Compression Tee Fitting is a flareless bite-type steel compression fitting from the 7000 Series Ermeto, with a 3/8 in OD size and 1/4"-18 thread size (MPN 7755X06X04X06). 3G Electric interprets…

SKU 3G-OTH-470220

Brand
WEATHERHEAD
Item
Compression Tee Fitting: 3/8 in OD x 1/4 in Pipe x 3/8 in OD Size
Category
Flareless Bite-Type Steel Compression Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

WEATHERHEAD
Manufacturer Part Number
7755X06X04X06
Series
7000 Series Ermeto
OD Size
3/8 in
Thread Size
1/4"-18
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

WEATHERHEAD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The WEATHERHEAD Compression Tee Fitting is a flareless bite-type steel compression fitting from the 7000 Series Ermeto, with a 3/8 in OD size and 1/4"-18 thread size (MPN 7755X06X04X06). 3G Electric interprets customer demand and delivers this genuine industrial fitting across 14 departments — and far more — with specialist depth in combustion, pumps and controls as an authorised distributor.

Frequently Asked Questions

What is a WEATHERHEAD Compression Tee Fitting used for?

The WEATHERHEAD Compression Tee Fitting is used to create a leak-tight branch connection in hydraulic or pneumatic tubing systems. It is a flareless bite-type steel fitting from the 7000 Series Ermeto, ideal for high-pressure industrial applications across machining, power transmission, and material handling.

What are the specifications of the WEATHERHEAD 7755X06X04X06?

The WEATHERHEAD 7755X06X04X06 is a 7000 Series Ermeto compression tee fitting. It has a 3/8 in OD tube size, a 1/4 in pipe branch, and a 1/4"-18 thread size. It is made of steel with a flareless bite-type design for reliable sealing in hydraulic systems.

Where to buy WEATHERHEAD compression fittings worldwide?

3G Electric supplies genuine WEATHERHEAD compression fittings worldwide. We handle full logistics, customs clearance, and delivery to your site. As a global industrial solutions provider, we source the 7000 Series Ermeto fittings and support your procurement across 14 departments.

How to install a flareless bite-type compression fitting?

To install a WEATHERHEAD flareless bite-type fitting, cut the tube square, deburr, and slide the nut and ferrule onto the tube. Insert the tube into the body until it seats, then tighten the nut to the manufacturer's recommended torque. Over-tightening can damage the bite ring.

Used in

Common applications for WEATHERHEAD
Mobile hydraulic systems — Weatherhead hydraulic flange fittings (e.g., 12Z-G42) for hose assemblies in excavators and loaders
Pneumatic tool lines — Weatherhead quick-connect couplings (e.g., 430) for air supply connections in manufacturing plants
Industrial machinery — Weatherhead 45° elbow flange fittings (e.g., 20Z-G54) for hydraulic power units
Fluid transfer systems — Weatherhead straight flange fittings (e.g., 16Z-G20) for high-pressure oil lines
Maintenance and repair — Weatherhead quick-connect bodies (e.g., 580) for replacing worn couplings on pneumatic tools
Hydraulic press applications — Weatherhead 90° elbow flange fittings (e.g., 24Z-G84) for compact hose routing in tight spaces

WEATHERHEAD Products

3G Electric supplies WEATHERHEAD flareless bite-type steel compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
