WESTWARD Hydraulic Toe Jack: Steel, Manual Handle, Mechanical, 5 ton Load Capacity - Low-Clearance Toe Jacks
WESTWARDLow-Clearance Toe Jacks

WESTWARD Hydraulic Toe Jack: Steel, Manual Handle, Mechanical, 5 ton Load Capacity

The WESTWARD Hydraulic Toe Jack is a low-clearance toe jack with a steel body, designed for lifting applications requiring a 5 ton load capacity and a minimum lift of 7/8 in. It features a manual handle lifting…

SKU 3G-OTH-481394

Brand
WESTWARD
Item
Hydraulic Toe Jack: Steel, Manual Handle, Mechanical, 5 ton Load Capacity
Category
Low-Clearance Toe Jacks
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

WESTWARD
Manufacturer Part Number
1VW31
Type
Manual Handle, Mechanical, 5 ton Load Capacity
Lift
7/8 in Min
Body Material
Steel
Lifting Actuator
Manual Handle
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

WESTWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The WESTWARD Hydraulic Toe Jack is a low-clearance toe jack with a steel body, designed for lifting applications requiring a 5 ton load capacity and a minimum lift of 7/8 in. It features a manual handle lifting actuator and is identified by manufacturer part number 1VW31.

Frequently Asked Questions

What is a WESTWARD Hydraulic Toe Jack used for?

A WESTWARD Hydraulic Toe Jack is used for lifting heavy loads in tight spaces where conventional jacks cannot fit. Its low-clearance toe design allows positioning under machinery, skids, or equipment with minimal ground clearance. Common applications include industrial maintenance, construction, and material handling.

What are the specifications of the WESTWARD 1VW31 toe jack?

The WESTWARD 1VW31 Hydraulic Toe Jack has a 5 ton load capacity, a minimum lift of 7/8 in, and a steel body. It uses a manual handle lifting actuator and is mechanically operated. This model is designed for low-clearance lifting tasks in industrial environments.

Where to buy a WESTWARD Hydraulic Toe Jack worldwide?

3G Electric supplies the WESTWARD Hydraulic Toe Jack 1VW31 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time; we source genuine industrial equipment across 14 departments to meet your needs.

How to maintain a WESTWARD Hydraulic Toe Jack?

To maintain a WESTWARD Hydraulic Toe Jack, keep the ram and toe clean and free of debris. Check hydraulic fluid level periodically and inspect for leaks or damage. Store in a dry location and lubricate moving parts as recommended by the manufacturer. Always follow the manual for safe operation.
