WHITE-RODGERS Magnetic Relay: Surface Mounted, 125 mA Current Rating, 24V AC, SPDT - Surface-Mounted Relays
WHITE-RODGERSSurface-Mounted Relays

WHITE-RODGERS Magnetic Relay: Surface Mounted, 125 mA Current Rating, 24V AC, SPDT

The WHITE-RODGERS Magnetic Relay is a surface-mounted relay with a universal mounting style and quick-connect electrical connection. It features an SPDT configuration with 5 pins/terminals, a 125 mA current rating at…

SKU 3G-OTH-36342

Brand
WHITE-RODGERS
Item
Magnetic Relay: Surface Mounted, 125 mA Current Rating, 24V AC, SPDT
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

WHITE-RODGERS
Manufacturer Part Number
90 293Q
Type
125 mA Current Rating, SPDT
AC
24V
Mounting Style
Universal
Pins/Terminals
5
Operating Current
8 A at 125/250V AC (Inductive Load)
Electrical Connection
Quick-Connect
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

WHITE-RODGERS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The WHITE-RODGERS Magnetic Relay is a surface-mounted relay with a universal mounting style and quick-connect electrical connection. It features an SPDT configuration with 5 pins/terminals, a 125 mA current rating at 24V AC, and an operating current of 8 A at 125/250V AC (inductive load). This relay is identified by manufacturer part number 90 293Q.

Frequently Asked Questions

What is the WHITE-RODGERS 90 293Q magnetic relay used for?

The WHITE-RODGERS 90 293Q magnetic relay is used for switching inductive loads in HVAC, burner, and industrial control circuits. Its SPDT configuration and 8 A at 125/250V AC rating make it suitable for fan, pump, and compressor control in commercial and light industrial applications.

What are the specifications of the WHITE-RODGERS 90 293Q relay?

The WHITE-RODGERS 90 293Q is a surface-mounted magnetic relay with universal mounting, quick-connect terminals, and 5 pins. It operates at 24V AC with a 125 mA current rating and handles 8 A at 125/250V AC (inductive load). The SPDT configuration provides versatile switching for control systems.

Where to buy the WHITE-RODGERS 90 293Q relay worldwide?

3G Electric supplies the WHITE-RODGERS 90 293Q magnetic relay to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this relay and other industrial controls.

How to install a WHITE-RODGERS surface-mounted relay?

Mount the WHITE-RODGERS 90 293Q relay on a clean, flat surface using the universal mounting holes. Connect wiring via the quick-connect terminals per the SPDT schematic, ensuring 24V AC coil voltage is applied. Verify load current does not exceed 8 A at 125/250V AC. Follow standard lockout/tagout procedures.
