WINSMITH Speed Reducer: 100:1, 17 RPM, 0.25 hp Input Max, 533 in-lb Output Max, Keyed
The WINSMITH Speed Reducer: 100:1 is a direct-drive right-angle speed reducer from WINSMITH, model E24MWNS with a 100:1 ratio and 56C frame. It delivers 17 RPM output, with a maximum input of 0.25 hp and maximum…
SKU 3G-OTH-139392
Also listed as: E24MWNS100156C · E24MWNS 100 1 56C · E24MWNS-100-1-56C
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The WINSMITH Speed Reducer: 100:1 is a direct-drive right-angle speed reducer from WINSMITH, model E24MWNS with a 100:1 ratio and 56C frame. It delivers 17 RPM output, with a maximum input of 0.25 hp and maximum output torque of 533 in-lb, featuring a keyed shaft.
Frequently Asked Questions
What is the WINSMITH Speed Reducer 100:1 used for?
The WINSMITH Speed Reducer 100:1 is a direct-drive right-angle speed reducer used to reduce motor speed and increase torque in industrial machinery. It is commonly applied in conveyors, packaging equipment, and material handling systems where precise speed reduction and reliable torque transmission are required.
What are the specifications of the WINSMITH Speed Reducer 100:1?
The WINSMITH Speed Reducer model E24MWNS has a 100:1 ratio, 56C frame, keyed shaft, 17 RPM output, 0.25 hp maximum input, and 533 in-lb maximum output torque. It is a direct-drive right-angle unit from WINSMITH, designed for industrial applications.
Where to buy WINSMITH Speed Reducer 100:1 worldwide?
You can source the WINSMITH Speed Reducer 100:1 worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.
How to select the right WINSMITH Speed Reducer for my application?
To select the right WINSMITH Speed Reducer, match the required output speed and torque to the unit's specifications. For the 100:1 model, ensure your motor input does not exceed 0.25 hp and that the frame size (56C) aligns with your motor. Consult a WINSMITH catalog for application guidelines.
Used in
Common applications for WINSMITHWINSMITH Products
3G Electric supplies WINSMITH direct-drive right-angle speed reducers. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
