Approved Vendor 3G-OTH-534070 — Technical Specifications
The APPROVED VENDOR Self Locking Thread Insert is a standard-wall, inch-system insert with #8-32 internal thread size and 5/16"-18 external thread size, plain finish. It features coarse thread type, 2A external thread fit, and 2B internal thread fit, compatible with a 5/16"-18 tap. This self-locking insert is part of a kit for installing threaded inserts in industrial applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | #8-32 Int Thrd Sz, Plain |
| Wall Type | Standard Wall |
| Ext Thrd Sz | 5/16"-18 |
| Thread Type | Coarse |
| Compatible Tap Size | 5/16"-18 |
| External Thread Fit | 2A |
| Internal Thread Fit | 2B |
| System Of Measurement | Inch |
| Manufacturer Part Number | EZ-303-008 |
