Approved Vendor 3G-OTH-534063 — Technical Specifications
The APPROVED VENDOR Self Locking Thread Insert is a thin-wall, inch-system insert with a 3/8"-24 internal thread (2B fit) and a 1/2"-20 external thread (2A fit). It requires a 29/64 drill bit and a 1/2"-20 compatible tap. This self-locking insert is designed for fine-thread applications where a thin-wall profile is needed.
Technical Specifications
| Parameter | Value |
|---|---|
| Wall Type | Thin Wall |
| Ext Thrd Sz | 1/2"-20 |
| Int Thrd Sz | 3/8"-24 |
| Thread Type | Fine |
| Drill Bit Size | 29/64 |
| Compatible Tap Size | 1/2"-20 |
| External Thread Fit | 2A |
| Internal Thread Fit | 2B |
| System Of Measurement | Inch |
| Manufacturer Part Number | EZ-313-624 |
