Ashcroft 3G-OTH-36232 — Technical Specifications
The ASHCROFT Pressure Switch: Piston Actuator (MPN APAN41H00MHB025000#-NSR) is a diaphragm and piston miniature pressure switch with a 1NO/1NC contact configuration and a pressure range of 500 psi to 5,000 psi. It features a 1/4" MNPT pressure connection and a Micro DIN Connector for electrical connection.
Technical Specifications
| Parameter | Value |
|---|---|
| MNPT | 1/4" |
| Type | 1NO/1NC, 500 psi – 5,000 psi |
| Brand | ASHCROFT |
| Manufacturer Part Number | APAN41H00MHB025000#-NSR |
| Pressure Connection Type | 1/4" MNPT |
| Electrical Connection Type | Micro DIN Connector |
