B&k Precision 3G-OTH-174390 — Technical Specifications
The B&K PRECISION 1715A is a digital DC power supply with a maximum current output of 2 A. It features line regulation voltage of less than 0.01% + 3 mV, load regulation voltage of less than 0.01% + 3 mV, line regulation current of 0.2% + 3 mA, load regulation current of 0.2% + 3 mA, and ripple voltage regulation of 1 mV. The unit measures 6.2 in H x 5.5 in W x 12.5 in D and includes an AC power cord. It is not certified with a calibration certificate.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | 6.2 in H x 5.5 in W x 12.5 in D |
| Brand | B&K PRECISION |
| Includes | AC Power Cord |
| Power Supply Type | Digital DC |
| Current Output Max | 2 A |
| Line Regulation Current | 0.2% + 3 mA |
| Line Regulation Voltage | Less Than 0.01% + 3mV |
| Load Regulation Current | 0.2% + 3mA |
| Load Regulation Voltage | Less Than 0.01% + 3 mV |
| Manufacturer Part Number | 1715A |
| Ripple Voltage Regulation | 1 mV |
| Calibration Certificate Type | Not Certified |
