Chainflex 3G-OTH-51025 — Technical Specifications

Name: Chainflex 3G-OTH-51025 CHAINFLEX Control Cable: 18 AWG, 36 Conductors, Order by the Foot, PVC Jacket, 300 V (MPN CF130-07-36). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 4 x OD; Minimum Bend Radius Factor - Flexible: 6 x OD; Includes Ground: Yes; Minimum Bend Radius Factor - E-Chain: 7.5 x OD; Resistance Properties: Flame Retardant; Standards: EAC TC RU C-DE. ME77.B.01254.
Brand: Chainflex

The CHAINFLEX Control Cable: 18 AWG (SKU 801J48) is a continuous flexing control cable from the Chainflex series, featuring 36 copper conductors with a single conductor configuration and a PVC jacket rated for 300 V. It includes a ground conductor and is flame retardant, with minimum bend radius factors of 4 x OD for fixed installation, 6 x OD for flexible use, and 7.5 x OD for e-chain applications. This cable complies with EAC TC RU C-DE. ME77.B.01254 standards and is sold by the foot.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Order by the Foot, PVC Jacket, 300 V
Brand	CHAINFLEX
Series	Chainflex
Standards	EAC TC RU C-DE. ME77.B.01254
Conductors	36
Cable Series	CF130-UL
Product Type	Control Cable
Includes Ground	Yes
Conductor Material	Copper
Resistance Properties	Flame Retardant
Conductor Configuration	Single
Manufacturer Part Number	CF130-07-36
Minimum Bend Radius Factor - Fixed	4 x OD
Minimum Bend Radius Factor - E-Chain	7.5 x OD
Minimum Bend Radius Factor - Flexible	6 x OD
