Chainflex 3G-OTH-47057 — Technical Specifications

Name: Chainflex 3G-OTH-47057 CHAINFLEX Motor Cable: 10 AWG, 1 Conductors, Order by the Foot, PVC Jacket, 600 V (MPN CF885-100-01). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 8 x OD; Minimum Bend Radius Factor - Flexible: 12 x OD; Includes Ground: No; Minimum Bend Radius Factor - E-Chain: 15 x OD; Resistance Properties: Oil and Grease Resistant; Standards: VW-1.
Brand: Chainflex

The CHAINFLEX CF885-100-01 is a continuous flexing power cable, specifically a 10 AWG single-conductor motor cable with a copper conductor and PVC jacket. Rated at 600 V, it is oil and grease resistant, VW-1 compliant, and includes no ground conductor. Its minimum bend radius factors are 8 x OD for fixed installation, 12 x OD for flexible use, and 15 x OD for e-chain applications.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Order by the Foot, PVC Jacket, 600 V
Brand	CHAINFLEX
Series	Chainflex
Standards	VW-1
Conductors	1
Cable Series	CF885
Product Type	Motor Cable
Includes Ground	No
Conductor Material	Copper
Resistance Properties	Oil and Grease Resistant
Conductor Configuration	Single
Manufacturer Part Number	CF885-100-01
Minimum Bend Radius Factor - Fixed	8 x OD
Minimum Bend Radius Factor - E-Chain	15 x OD
Minimum Bend Radius Factor - Flexible	12 x OD
