Chainflex 3G-OTH-46969 — Technical Specifications

Name: Chainflex 3G-OTH-46969 CHAINFLEX Motor Cable: 3/0 AWG, 1 Conductors, Order by the Foot, PVC Jacket, 600 V (MPN CF885-950-01). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 8 x OD; Minimum Bend Radius Factor - Flexible: 12 x OD; Includes Ground: No; Minimum Bend Radius Factor - E-Chain: 15 x OD; Resistance Properties: Flame Retardant; Standards: CE 2014/35/EU.
Brand: Chainflex

The CHAINFLEX Motor Cable: 3/0 AWG is a continuous flexing power cable from the Chainflex CF885 series, featuring a single copper conductor with a PVC jacket rated at 600 V. It is flame retardant, complies with CE 2014/35/EU, and has minimum bend radius factors of 8 x OD for fixed, 12 x OD for flexible, and 15 x OD for e-chain applications. This cable does not include a ground conductor and is sold by the foot.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Order by the Foot, PVC Jacket, 600 V
Brand	CHAINFLEX
Series	Chainflex
Standards	CE 2014/35/EU
Conductors	1
Cable Series	CF885
Product Type	Motor Cable
Includes Ground	No
Conductor Material	Copper
Resistance Properties	Flame Retardant
Conductor Configuration	Single
Manufacturer Part Number	CF885-950-01
Minimum Bend Radius Factor - Fixed	8 x OD
Minimum Bend Radius Factor - E-Chain	15 x OD
Minimum Bend Radius Factor - Flexible	12 x OD
